Hypertherm Powermax 900 User Manual

230V CE INSTALLATION
230V CE Installation Manual
2-7
U V W
Remove power
cord wires from
TB1 and ground
stud.
Green/
Yellow
Black
Blue
Brown
TB1
Figure 2-5 Removal of Power Cord from Powermax900 CE Power Supply - 2 of 2
GND
3.5.Remove toroid from power cord wires. Save the toroid. See Figure 2-6.
3.5.Remove the power cord from the rear panel.
Figure 2-6 Removal of Toroid from Power Cord
Unwind power cord
wires from toroid.
Save toroid
Toroid
