Service Manual

PARTS LIST - 208/240/480V

POWER SUPPLY - 208/240/480V

Rear

Index No. Part No. Description Ref. Desig. Quantity

1 001503 Pnl:Powermax800/900 Pwr Unit Plastic Rear 1

2 129068 Circuit Breaker SA:4Pole 480V W/TC S1 1

3 128405 Contactor Replacement:Powermax800/900 CR1 1

129300 Regulator SA:Powermax800/900 Pwr Unit 1

4 011072 Filter:20 Micron 1/8FPT 1

5 015285 Male Connector:1/8NPTX1/4Push in Tube 1

6 011079 Filter Element for 011072 Filter 1

129327 Linecord Panel SA:Powermax900 208/240/480V 1

7 001660* Panel:Powermax900 Power Cord 1

8 008228 Cord Grip:1NPT .690-.990 2Screws 1

9 129114 Power Cord SA:Powermax800/900 1

10 123099** Cable: Powermax800/900 Machine Interface

Notes: Bold part numbers and descriptions are subassemblies.

Indented normal type items are components of subassemblies

All mounting hardware in power supply drawings shown for reference only.

* Use 129332 to order power cord rear panel for 208/240/480V power supplies if you

have the machine interface option.

** Available only with the machine interface option.

See also Section 5 Parts List - 200/230/400V, and Section 6 Parts List - 400V CE

to identify parts for other Powermax900 power supplies.
