6-11
PARTS LIST - 400V CE
Service Manual
RECOMMENDED SPARE PARTS - POWERMAX900 400V CE
Page
Part Number Description Reference
003078 ............................... Relay:30A NO Mag Blwt QDisc Term................................................. 6-5
003132 ............................... Circuit Breaker SA:4Pole 480V W/TC ................................................ 6-9
128405 ............................... Contactor Replacement:Powermax800/900 ....................................... 6-9
008958 ............................... Fuse:1A 500V 10mm X 38mm GI Slo(2) ............................................ 6-5
008959 ............................... Fuse:20A 500V 10mm X 38mm GI Slo(3) .......................................... 6-5
014209 ............................... Xfmr:Powermax800/900 CE 400V Control ......................................... 6-7
014229 ............................... Xfmr:Powermax900 200/230/400 Power ............................................ 6-7
014230 ............................... Inductor:Powermax900 0.8MH 55A.................................................... 6-7
023922 ............................... Cable w/Clamp:PMX800/900 Work 20' .............................................. 6-3
027443 ............................... Fan:260CDM 120VAC 50-60HZ ......................................................... 6-7
005112 ............................... Pressure Switch:39 Psi .013 Orifice ................................................... 6-3
006110 ............................... Sol. Valve:100# 1/8FPT 24VAC 3W ................................................... 6-3
011072 ............................... Filter:20 Micron 1/8FPT ...................................................................... 6-9
011079 ............................... Filter Element for 011072 Filter .......................................................... 6-9
011073 ............................... Regulator:0-125 Psig 1/8FPT ............................................................. 6-3
022027 ............................... Press. Gauge:160# 1.5" 1/8CBM Panel ............................................. 6-3
129046 ............................... Heatsink SA:Powermax800/900 CE Power Unit ................................ 6-5
109018/008906 .................. Diode:600V 100A UFast Recovery Dual (2)
/Thermal Pad:AL-380-100 (2) ............................................................. 6-5
109043/008947 .................. Diode:1600V 30A 3PH Bridge/Thermal Pad:AL-315-114................... 6-5
009849/008903 .................. Resistor:20-Ohm 50W 5% NON-IND (4)
/Thermal Pad:AL-197-114 (4) ............................................................. 6-5
009850/008902 .................. Resistor:20-Ohm 25W 5% NON-IND (4)
/Thermal Pad:AL-103-108 (4) ............................................................. 6-5
029998/008905 .................. IGBT Gate Drive SA:Powermax800/.900 (2)
/Thermal Pad:AL-370-134 (2) ............................................................. 6-5
041668 ............................... PCB Assy:Powermax900 Micro Control ............................................. 6-5
041532 ............................... PCB Assy:Powermax800/900-ZB Power..................................... 6-5, 6-7
129049 ............................... Electric Line Filter SA:Powermax800/900-CE .................................... 6-9
129376 ............................... Power Cord SA:Powermax900-CE..................................................... 6-9
028908 ............................... Kit:Powermax800/900 Cooling Fan Filter ........................................... 5-7
9-99
