PARKING BRAKE
2. SPECIFICATION
DISK BRAKE
There are two brake systems, the foot brake system and the hand brake system.
The foot brake adopts the brake system of oil type at drive axle.
Oil pressure is generated in maximum 140
kgf/cm
2
through brake oil input path of the left and right
drive axle housing, this pressure allows the piston brake to advance and compresses a friction plate
and a plate.
So when the transportation travels, it is possible to brake.
The parking brake works by the hand brake installed on parking drum which is linked to the output
shaft of the forward clutch.
4-1
GROUP 1 STRUCTURE AND FUNCTION
SECTION 4 BRAKE SYSTEM
1. OUTLINE
1)
2)
Item
Type
Parking lever stroke / Cable stroke
Ratchet, internal expanding mechanical type
12.1
。/ 11.5mm
Specification
Item
Type
Master cylinder diameter (Non boosted)
Pedal adjustment
Brake oil
Azola ZS10 (SAE 10W hydraulic oil)
Wet disk brake
Pedal height
Play
33
mm (
1.3
in)
160
mm
1
~
3
mm
Specification
