Hyundai 20L-7 User Manual

7-1
GROUP 1 COMPONENT LOCATION
SECTION 7 ELECTRICAL SYSTEM
1 Flasher lamp
2 Work lamp
3 Combination switch
4 Horn assembly
5 Combination lamp
6 Back buzzer
7 Forward-reverse lever
8 Operating panel
9 Start switch
10 Horn button
11 Switch assembly
12 Fuse box
13 OPSS unit
14 Flasher unit
15 Battery
20L7EL02

Hyundai 20L-7 Specifications

General

Brand	Hyundai
Model	20L-7
Category	Forklifts
Language	English
