Hyundai HYM3800E User Manual

Operation
25
www.hyundaipowerproducts.co.uk
01646 687 880 sales@hyundaipowerproducts.co.uk
Cutting Height Adjustment
Position 1 is the lowest and 5 is the highest. If your grass is quite long, set the height to a
high position first and take an initial cut.
1
You can adjust the height to 5 positions.
This is the lowest height setting.
This is the highest height setting.
5
1
Rear Roller
The rear roller will enable the mower to
provide attractive stripes to the lawn. It is
spring loaded so it self adjusts to the required
height.

Hyundai HYM3800E Specifications

General

Type	Push lawn mower
Cutting width	380 mm
Grass catcher	Yes
Product color	Black, Blue
Number of wheels	4 wheel(s)
Rotational speed	3700 RPM
Maximum lawn area	185 m²
Maximum cutting height	70 mm
Minimum cutting height	20 mm
Grass collecting volume	40 L
Number of height positions	5
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	1320 mm
Width	450 mm
Height	920 mm
Weight	12500 g
Package depth	700 mm
Package height	410 mm
Package weight	14000 g
