Hyundai HYM3800E User Manual

Troubleshooting
Maintenance
33
www.hyundaipowerproducts.co.uk
01646 687 880 sales@hyundaipowerproducts.co.uk
For faults not listed in this table, or which you cannot resolve by yourself, please
contact our aftersales team. Where necessary, all corrective actions should be carried
out by suitably qualified persons.
!
Motor won’t start • Check the fuse in the plug.
• Check the cable for damage.
• Make sure you are holding in the RED button while pulling the
OPC lever.
• If the motor is hot, leave to cool down and try again.
• Check underneath for excessive build-up of grass clippings
which may be jamming the blade.
Mower not collecting grass • Make sure mulching plug is removed.
• Clean under the deck of the mower and the exit chute into the
grass collector.
Mower does not cut grass
cleanly.
• Check if the blade is blunt. Sharpen or replace if needed.
• Check that the cutting height suits the grass length.
Wheels
The wheels can be removed for greasing with a general purpose grease before each grass
cutting season.
1
Pull the wheel trim off and remove the R Clip. Slide the wheel off and apply some grease to
the axle.
2

Hyundai HYM3800E Specifications

General

Type	Push lawn mower
Cutting width	380 mm
Grass catcher	Yes
Product color	Black, Blue
Number of wheels	4 wheel(s)
Rotational speed	3700 RPM
Maximum lawn area	185 m²
Maximum cutting height	70 mm
Minimum cutting height	20 mm
Grass collecting volume	40 L
Number of height positions	5
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	1320 mm
Width	450 mm
Height	920 mm
Weight	12500 g
Package depth	700 mm
Package height	410 mm
Package weight	14000 g
