Spare Parts
Drawing Number Spare Part Name Part Number
HYM3800E-G1 Right Fan Window Part 1132073
HYM3800E-G2 Left Fan Window Part 1132074
HYM3800E-G3 Screw 1286019
HYM3800E-G4 Height Adjusting Board 1286059
HYM3800E-G5 Upper Handle 1132077
HYM3800E-G6 Cable Clamp 1286061
HYM3800E-G7 Lower Handle 1286062
HYM3800E-G8 Quick Release Handle 1286063
HYM3800E-G9 Pin 1286064
HYM3800E-G10 Pin for Quick Release Handle 1286065
HYM3800E-G11 Limit Base for Quick Release
Handle
1286066
HYM3800E-G12 Washer 1290007
HYM3800E-G13 Knob 1290008
HYM3800E-G14 Washer 1286069
HYM3800E-G15
Right Buckle for Lower Handle
1286070
HYM3800E-G16 Right Buckle 1286071
HYM3800E-G17 Pressed Board 1290028
HYM3800E-G18 Nut 1286073
HYM3800E-G19 Screw 1286074
HYM3800E-G20 Left Buckle 1286075
HYM3800E-G21 Left Buckle for Lower Handle 1286076
HYM3800E-G22 Lower Deck 1286077
HYM3800E-G23 Side Cover 1286078
HYM3800E-G24 Plastic Blade Adaptor 1286079
HYM3800E-G25 Blade 1286080
HYM3800E-G26 Washer 1288042
HYM3800E-G27 Bolt 1286082
HYM3800E-G28 Washer 1286083
HYM3800E-G29 Pressed Cap for Cable 1292067
HYM3800E-G30 Foam of Handle 1286084
HYM3800E-G31 ST Screw 1286055
HYM3800E-G32 Clip Buckle for Lower Cover 1286086
HYM3800E-G33 Capacitance 1292068
HYM3800E-G34 ST Screw 1189034
HYM3800E-G35 Nylon Belt 1286054
HYM3800E-G36 ST Screw 1132108
Drawing G

Hyundai HYM3800E Specifications

General

Type	Push lawn mower
Cutting width	380 mm
Grass catcher	Yes
Product color	Black, Blue
Number of wheels	4 wheel(s)
Rotational speed	3700 RPM
Maximum lawn area	185 m²
Maximum cutting height	70 mm
Minimum cutting height	20 mm
Grass collecting volume	40 L
Number of height positions	5
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	1320 mm
Width	450 mm
Height	920 mm
Weight	12500 g
Package depth	700 mm
Package height	410 mm
Package weight	14000 g
