Drive Cable Adjustment
20
Drive Cable Adjustment
NOTE - It is necessary as part of
routine maintenance to adjust the drive
cable tension to ensure the lawnmower will
self-propel correctly.
If there is more than 10mm movement in the
drive lever before the cable begins to move,
then the drive cable will require adjustment.
!
STEP 1
Follow the drive cable down towards the
lawnmower until you reach the drive cable
adjuster.
Lock Nut
Adjustment
Nut
STEP 2
Undo the lock nut and wind it forwards.
STEP 3
Wind the adjuster nut towards the main
handlebar. As you adjust, keep checking the
tension on the drive cable until the desired
tension is reached.
STEP 4
Tighten the lock nut finger tight, back towards
the adjuster nut and check for drive on the
lawn mower. Once drive is restored, tighten
the lock nut securely.
