Specifications
25
NOTE - All machines are tested and inspected so there may be some residual oil left in the
machine so please fill with caution.
MODEL
HYM42P-B
HYM460SPE HYM510SP
Engine Type HYUNDAI IC140V HYUNDAI IC140VE
HYUNDAI IC175V
Engine Size 139cc 139cc
173cc
Fuel Tank Capacity 1L 1L 1L
Fuel Type Straight Unleaded
Petrol
Straight Unleaded
Petrol
Straight Unleaded
Petrol
Oil Capacity
Oil Type
600ml
SAE 30 OR 15W40
600ml
SAE 30 OR 15W40
600ml
SAE 30 OR 15W40
Rated Speed
2800rpm 2800rpm 2800rpm
Rated Power 2.6kW 2.6kW
3.6kW
Drive Type
Hand Push
Self-Propelled Self-Propelled
Start Method
Recoil Start
Electric & Recoil Start
Recoil Start
Height Adjustment 6 Position 6 Position 6 Position
Cutting Height 25-75mm 25-75mm 25-75mm
Cutting Width 420mm 457mm 508mm
Grass Collector Type Half Plastic With
Polyester Bag
Half Plastic With
Polyester Bag
Half Plastic With
Polyester Bag
Grass Collector Volume 45L 70L 70L
Deck Material Steel Steel Steel
Wheel Size Front 152mm 178mm 203mm
Wheel Size Rear
Measured Sound Level
Guaranteed Sound Level
Vibrations
178mm
94.49dB(A)
96dB(A)
5.361m/s2 K=1.5 m/s²
254mm
95dB(A)
96dB(A)
9.794m/s2 K=1.5 m/s²
280mm
97dB(A)
98dB(A)
3.12m/s2 K=1.5 m/s²
Handle Type
Start Method
Dimensions (L x W x H)
Soft Grip Handle
Recoil Start
1300 x 470 x 1050mm
Soft Grip Handle
Electric & Recoil Start
1440 x 530 x 1050mm
Soft Grip Handle
Recoil Start
1580 x 550 x 1050mm
Weight
26.0kg
38.0kg 37.0kg
Function Rear Discharge,
Mulching, Collect
Rear Discharge,
Mulching, Side
Discharge, Collect
Rear Discharge,
Mulching, Side
Discharge, Collect
