VEHICLE SPECIFICATIONS
2
J010A01FC-GAT
MEASUREMENT
4,025(158.4)
1,740(68.5)
1,635(64.3)
*1,685(66.3)
2,600(102.3)
1,485 (58.5)
1,485 (58.5)
Overall length
Overall width
Overall height (unladen)
Wheel base
Wheel tread
Front
Rear
Type
Wheel free play
Rack stroke
Oil pump type
Rack and pinion
0 ~ 30 mm (0 ~ 1.18 in.)
146±1mm (5.7±0.04 in.)
Vane type
J060A01S-GAT
FUEL SYSTEM
J020A01FC-GAT
POWER STEERING
J030A01FC-GAT
TIRE
185/65 R14
195/55 R15
205/55 R15 (1.8 DOHC only)
Standard
Option
J050A01FC-GAT
BRAKE
Dual hydraulic with brake booster
Ventilated disc
Drum
Cable
Type
Front brake type
Rear brake type
Parking brake
Item
Battery
Generator
J040A03FC-GAT
ELECTRICAL
GASOLINE
MF45AH, MF60AH(12V)
90A (13.5V)
mm (in.)
Fuel tank
capacity
Liter
55
US.gal
14.5
Imp.gal
12
DIESEL
CMF 68 AH
120A (12V)
*Installed roof rack
J030B01FC-GAT
SPARE TIRE
Temporary
Full size
Standard
Option
258
260
