ATTENTION:
Alwaysconnectthe(negative)terminalbeforeandthe+(positive)terminalafter.
Alwaysdisconnectthebatteryinoppositeorder.
§ Rechargethebatteryatleastonceevery6months.
§ Never put the battery in contact with solvents, gasolines, oils, plastifiers or rags
containingsuchelements.Theexternalcaseofthebatterycouldbedamaged.
§ Neverpressorbendoroverheat(bywelding)thebatteryterminals.
Otherrecommendations
§ Payattentionnottohavefreefiresuponoraroundthebattery.
§ Nevershortcircuittheterminals.
§ Neveropenthebatteryorthrowitinthefire.
§ In case the electrolite (diluted Sulfuric acid) gets in contact with skin or clothes,
immediately wash with water. In case it gets in touch with eyes, wash and apply for
medicalassistance.
§ Carefully check the external case of battery and replace in case of breakages,
swellingsofthecaseorofbatterycover.
§ Beforeuse,cleanthebatteryfromdustandcheckthattheterminalsarenotoxidyzed
ordamaged.
§ When the battery comes to an end never throw it in the garbage but deliverit to an
authorizeddisposer.
14 WARNINGSONTHEELECTRICALSYSTEM
Weareherelistingthemainwarningsontheelectricalsystem.
Pleasekeepthisinmindduringthewholelifeoftheengine.
ATTENTION:
If these prescriptions are not followed the electrical system and the eng ine
couldbedamagedbeyondrepair.NoobligationofIAMEexistsinthiscase.
1) PleaseturnthekeytoSTOPpositioneverytimetheengineisstopped.Ifthekeyis
leftinKEYposition,foralongtime,eveniftheengineisstopped,thebatterywould
bedischargedcompletely.
2) Neverdisconnectthegroundcableswitheyeletswhentheengineisinoperation.
3) DisconnectingthebatterywhentheengineisinoperationDOESNOTincreasethe
engineperformance.Viceversa,theignitionadvancecouldbecomeveryirregular
atlowRPMthusreducingtheperformance.
4) Tofastentheeyeletterminal(groundings)ofthewiringharnessalwaysuseflator
openwashers.Neverusetabwashers.
5) Whendisconnectingtheconnectors,alwayspressthefixingtongues.Alwayspull
theconnectorstodisconnect.NEVERPULLTHECABLES.
6) The electronic box and the starting relay must always be installed with their
connector towards the bottom to avoid back water, dampness or dirt in the
connectorbody.
7) AlwayscorrectlyfixtheH.T.coilwithbothscrews,makesurethatthelaminations
packonH.T.coilisconnectedtotheenginewiththegroundingcable.Theeyelet
connectormustbedirectlyincontactwiththelaminationspackontheH.T.coil.
8) NeveruseH.T.coilsdifferentthantheoriginalcoilontheengine.Useofdifferent
coilmaycausedamagestotheelectronicbox.
