IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 15
Power supplies
Server power is derived from the power supplies installed in the BladeCenter chassis. There are no server
options regarding power supplies.
Integrated virtualization
The server supports VMware ESXi installed on a USB memory key. The key is installed in a USB socket
inside the server. The following table lists the virtualization options.
Table 14. Virtualization options
Part number Feature
code
Description Maximum
supported
41Y8298 A2G0 IBM Blank USB Memory Key for VMware ESXi Downloads 1
41Y8278 1776 IBM USB Memory Key for VMware ESXi 4 1
41Y8296 A1NP IBM USB Memory Key for VMware ESXi 4.1 Update 1 1
41Y8283 1749 IBM USB Memory Key for VMware ESXi 3.5 Update 5 1
41Y8287 3033 IBM USB Memory Key for VMware ESXi 4.1 1
41Y8311 A2R3 IBM USB Memory Key for VMware ESXi 5.1 1
41Y8300 A2VC IBM USB Memory Key for VMware ESXi 5.0 1
41Y8307 A383 IBM USB Memory Key for VMware ESXi 5.0 Update 1 1
Remote management
The server contains an IBM Integrated Management Module (IMM), which interfaces with the advanced
management module in the BladeCenter chassis. The combination of these two provides advanced
service-processor control, monitoring, and an alerting function. If an environmental condition exceeds a
threshold or if a system component fails, LEDs on the system board are lit to help you diagnose the
problem, records the error in the event log, and alerts you to the problem. A virtual presence capability is
also available for remote server management capabilities.
Remote server management is provided through industry-standard interfaces:
Intelligent Platform Management Interface (IPMI) Version 2.0

Simple Network Management Protocol (SNMP) Version 3

Common Information Model (CIM)

Web browser

The server also supports virtual media and remote control features, which provide the following functions:
Remotely viewing video with graphics resolutions up to 1600x1200 at 75 Hz, regardless of the system

state
Remotely accessing the server using the keyboard and mouse from a remote client

Mapping the CD or DVD drive, diskette drive, and USB flash drive on a remote client, and mapping

ISO and diskette image files as virtual drives that are available for use by the server
Uploading a diskette image to the IMM memory and mapping it to the server as a virtual drive

Capture blue-screen errors


IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
