IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 19
Regulatory compliance
The server conforms to the following international standards:
Australia and New Zealand C-Tick Mark, Class A

CE Mark (EN55022:1998 Class A, EN60950, EN55024:1998, EN61000-3-2 and EN61000-3-3)

CISPR 22, Class A

CSA C22.2 No.60950 Safety of Information Technology Equipment 60950

Canada ICES-003, issue 3, Class A

China GB 9254-1998, GB17625.1-1998, GB17625.2-1999

FCC - Verified to comply with Part 15 of the FCC Rules, Class A

IEC-60950 (CB Certificate and CB Test Report)

Japan VCCI, Class A

Korea MIC

NOM-019 Seguridad de Equipto de Procesamiento de Datos within 30 days of planned availability

TUV-GS (EN60950/ISO 9241-3/ISO 9241-8)

Taiwan BSMI CNS13438, Class A

UL 60950 Safety of Information Technology Equipment

External disk storage expansion
The HS22 supports attachments to external storage expansion enclosures such as the EXP3000 series,
using the ServeRAID-MR10ie Controller installed in the CIOv slot of the blade server. The HS22 can also
be attached to supported external storage systems, as described in the next section.
The external disk storage expansion enclosures listed in the following table are supported with the HS22.
Table 16. External storage expansion enclosures
Part number Description Maximum quantity
supported per blade
172701X IBM System Storage® EXP3000 1
174712X IBM System Storage EXP2512 Express 1
174724X IBM System Storage EXP2524 Express 1
SAS Connectivity Modules (one or two) must be installed into chassis to support external disk storage
expansion. SAS Connectivity Module is listed in the following table.
Table 17. SAS Connectivity Modules
Part number Description Maximum quantity supported per one chassis
39Y9195 SAS Connectivity Module 2
The RAID controller listed in the following table is supported with external expansion enclosures.
Table 18. RAID controllers for external storage expansion enclosures
Part number Description Maximum quantity
supported
46C7167 ServeRAID-MR10ie (CIOv) Controller with battery 1

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
