IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 22
External disk storage systems
The following table lists the external storage systems that are supported by server and that can be
ordered through the System x sales channel. The server might support other IBM disk systems that are
not listed in this table. For further information, refer to the IBM System Storage® Interoperability Center
at:
http://www.ibm.com/systems/support/storage/ssic
Table 23. External storage expansion
Part
number
Description Maximum quantity supported
per one blade server
17226xx IBM System Storage DS4300 Midrange Disk Systems (all models) 1
17429xx IBM System Storage DS4500 Midrange Disk System (all models) 1
17241xx IBM System Storage DS4100 Midrange Disk System (all models) 1
17421xx IBM System Storage DS4400 Midrange Disk System (all models) 1
181880C IBM System Storage DCS3700 1
18147Vx IBM System Storage DS4200 Midrange Disk System (all models) 1
18147xx IBM System Storage DS4700 Midrange Disk System (all models) 1
18158xx IBM System Storage DS4800 Midrange Disk System (all models) 1
1814-20A IBM System Storage DS5020 Midrange Disk System 1
181851x IBM System Storage DS5100 Midrange Disk System (all models) 1
181853x IBM System Storage DS5300 Midrange Disk System (all models) 1
For more information, see the list of IBM Redbooks Product Guides in the System Storage category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=externalstorage

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
