FRU Name Physical Location Code
Cooling Blowers
Cooling blower 1 U0.
dd -F1
Cooling blower 2 U0.
dd -F2
Cooling blower 3 U0.
dd -F3
Cooling blower 4 U0.
dd -F4
SPCN Connectors
SPCN connector 1 U0.
dd -P1/Q3
SPCN connector 2 U0.
dd -P1/Q4
SPCN connector 3 U0.
dd -P1/Q5
SPCN connector 4 U0.
dd -P1/Q6
Rack Indicator
Rack beacon (4–pin) U0.
dd -P1/Q7
Operator Panel
Operator panel U0.
dd -L1
Temperature Sensor
Temperature sensor (on operator panel) U0.
dd -L1
Disk Drives Backplanes
Disk drives backplane 1 U0.
dd -P3
Disk drives backplane 2 U0.
dd -P4
Disk Drive Locations
Hot-swap disk drive bay 1 U0.
dd -P1-Ix/Zn-A8
Hot-swap disk drive bay 2 U0.
dd -P1-Ix/Zn-A9
Hot-swap disk drive bay 3 U0.
dd -P1-Ix/Zn-AA
Hot-swap disk drive bay 4 U0.
dd -P1-Ix/Zn-AB
Hot-swap disk drive bay 5 U0.
dd -P1-Ix/Zn-AC
Hot-swap disk drive bay 6 U0.
dd -P1-Ix/Zn-AD
Hot-swap disk drive bay 7 U0.
dd -P1-Iy/Zn-A8
Hot-swap disk drive bay 8 U0.
dd -P1-Iy/Zn-A9
Hot-swap disk drive bay 9 U0.
dd -P1-Iy/Zn-AA
Hot-swap disk drive bay 10 U0.
dd -P1-Iy/Zn-AB
Hot-swap disk drive bay 11 U0.
dd -P1-Iy/Zn-AC
Hot-swap disk drive bay 12 U0.
dd -P1-Iy/Zn-AD
SCSI
SES0 U0.
dd -P1-Ix/Zn-AF
SES1 U0.
dd -P1-Iy/Zn-AF
Chapter 1. Reference Information
35
