Index Part number Units Description
23 24L1740 1 Air moving device assembly
dual 120mm (Note: one
part assembly replaces
AMD B01 and B02)
24 NONUM 1 Tape / tray assembly (see
the Type, model, and part
number list).
25 NONUM 1 Optical / tray assembly (see
the Type, model, and part
number list).
26 97H9137 1 Filler assembly
27 24L1591 1 Control panel assembly.
See Control panel - Models
270, 800, and 810.
28 24L1827 1 Shield, disk unit (EMC)
29 NONUM AR Disk unit assembly. See the
Type, model, and part
number list.
30 NONUM 1 Cage assembly, disk unit
(concurrent maintenance).
See types 28CD (See page
528) and 283F (See page
527) in the Type, model,
and part number list.
Cage assembly, disk unit
(non-concurrent
maintenance). See type
283E (See page 526) in
the Type, model, and part
number list.
31 75G2878 4 Screw, M3.5 x 8mm
32 04N3392 2 Screw, M3.5 x 8mm
Control panel assembly - Models 270, 800, and 810: For use by authorized service providers.
Figure 1. Control panel - Models 270, 800, and 810
Analyze hardware problems 373
