Addresses — Models 800 and 810
For use by authorized service providers.
Use the address to find the location. Then, go to Locations — Models 800 and 810 for additional
information.
Table 1. IOP, IOA, and device address information for Models 800 and 810
Position (listed in
IOA assignment
order)
Possible failing
component DSA (BBBBCcbb) Unit address
Note: IOA and device DSA’s will not follow
the rules below if the IOA is manually
reassigned after IPL.
MB1 Embedded IOP 0001-10-00 FFFFFFFF
MB1 Service
Processor
0001-70-00 FFFFFFFF
C07 Comm/Wkst IOA 0001-10-00 E1FFFFFF
C01 Storage IOA 0001-10-00 2FFFFFFF
C06 IOP 0001-13-00 FFFFFFFF
C06 Storage IOA 0001-10-00 3FFFFFFF
C06 Comm/Wkst IOA 0001-10-00 E3FFFFFF
C05 IOP 0001-14-00 FFFFFFFF
C05 Storage IOA The IOA has the same DSA as the first IOP
found in the following list: C06, MB1.
4FFFFFFF
C05 Comm/Wkst IOA The IOA has the same DSA as the first IOP
found in the following list: C06, MB1.
E4FFFFFF
C04 (IXS capable
position)
IOP 0001-15-00 FFFFFFFF
C04 (IXS capable
position)
Storage IOA The IOA has the same DSA as the first IOP
found in the following list: C05, C06, MB1.
5FFFFFFF
C04 (IXS capable
position)
Comm/Wkst IOA The IOA has the same DSA as the first IOP
found in the following list: C05, C06, MB1.
E5FFFFFF
C03 IOP 0001-16-00 FFFFFFFF
C03 Storage IOA The IOA has the same DSA as the first IOP
found in the following list: C04, C05, C06,
MB1.
6FFFFFFF
C03 Comm/Wkst IOA The IOA has the same DSA as the first IOP
found in the following list: C04, C05, C06,
MB1.
E6FFFFFF
C03 IXS attached IOA The IOA has the same DSA as the first IOP
found in the following list: C04, C05, C06,
MB1.
E506FFFF
C02 Storage IOA The IOA has the same DSA as the first IOP
found in the following list: C03, C04, C05,
C06, MB1.
7FFFFFFF
C02 Comm/Wkst IOA The IOA has the same DSA as the first IOP
found in the following list: C03, C04, C05,
C06, MB1.
E7FFFFFF
Analyze hardware problems 325
