IBM System x3100 M4 Type 2582 Problem Determination And Service Guide

Retaining
clips
Screws
9. If you are instructed to return the power-supply cage, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
Installing the hot-swap power supply cage
This procedure applies only to the 5U server model with hot-swap power supplies
(Model name: 2582-F4x).
To install the hot-swap power supply cage on the 5U server model with hot-swap
power supplies (Model name: 2582-F4x), complete the following steps.
1. Place the power-supply cage into the chassis and slide it toward the rear of the
server until the retaining clips engage the top of the chassis, then install the four
screws to secure the power-supply cage to the chassis.
Chapter 5. Removing and replacing server components 249

IBM System x3100 M4 Type 2582 Specifications

General

Form Factor	Tower
Chipset	Intel C202
Memory Slots	4 DIMM slots
Processor	Intel Pentium
Memory	Up to 32GB DDR3
Storage	Up to 4 x 3.5"
Power Supply	350W
Network Interface	Integrated Gigabit Ethernet
RAID Support	RAID 0, 1
Expansion Slots	1 PCI
USB Ports	6 x USB 2.0 (2 front, 4 rear)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
