Replaceable server components

Replaceable components are of three types:

v Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your

responsibility. If IBM installs a Tier 1 CRU at your request, you will be charged for

the installation.

v Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or

request IBM to install it, at no additional charge, under the type of warranty

service that is designated for your server.

v Field replaceable unit (FRU): FRUs must be installed only by trained service

technicians.

For information about the terms of the warranty and getting service and assistance,

see the Warranty and Support Information document.

Table 3. Parts listing, Type 7977

Index Description

CRU

part number

(Tier 1)

CRU

part number.

(Tier 2)

FRU

part number

1 Power supply, 835 W (models 12x, 22x, 42x, 52x, 62x,

72x, 82x, 92x, A2x, B2x, C2x, D2x, F2x, G2x, H2x, J2x,

L2x, M2x, Q4x, R2x, E1x, E2x, E4x, E5x, E7x, E3x, E6x,

E8x, E9x, EBx, EFx, EGx)

24R2731

2 Operator information panel assembly, with bracket and

cables

41Y9080

3 5.25 inch EMC flange (included in kit 39Y8355) 39Y8355

4 USB mounting bracket (model CTO) 41Y9068

5 DVD-ROM (primary) 39M3569

5 DVD-ROM (option) 39M3517

5 DVD-ROM (option) 39M3515

5 DVD-ROM, half-high (option) 43W4615

5 DVD-ROM, half-high, SATA (option) 43W8466

5 CD/RW/DVD combo drive (option) 43W4575

5 CD-ROM, 48X (option) 43W4615

5 CD-ROM, 48X (option) 39M3509

5 DVD-ROM (option) 39M3519

6 Half-high CD-ROM (option) 42C0953

6 Half-high combo drive (option) 39M0135

6 Half-high DVD-ROM (option) 43W4577

6 Half-high SATA DVD-ROM (option) 43W8467

6 Hard disk drive, 73 GB, 10K, SAS, HS (option) 39R7340

6 Hard disk drive, 146 GB, 10K, SAS, HS (option) 39R7342

6 Hard disk drive, 73 GB, 15K, SAS, HS (option) 39R7348

6 Hard disk drive, 146 GB, 15K, SAS, HS (option) 39R7350

6 Hard disk drive, 36 GB (option) 39R7346

6 Hard disk drive, 80 GB (option) 39M4521

6 Hard disk drive, 160 GB (option) 39M4525

42 IBM System x3500 Type 7977: Problem Determination and Service Guide
