Icom IC-78 Service Manualvice Man

[LOGIC BOARD][LOGIC BOARD]
S.=Surface mount
R103 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R104 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R105 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R106 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R107 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R108 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R111 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R112 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R113 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R114 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R115 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R116 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R117 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R118 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R119 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R126 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R127 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R128 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R129 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R130 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R131 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R132 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R133 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R134 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R135 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R136 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R137 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R138 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R139 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R141 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R142 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R143 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R144 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R145 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R146 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R147 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R148 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R149 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R150 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R151 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R153 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R154 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R156 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R158 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R160 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R161 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R162 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R163 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R164 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R165 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R166 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R169 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R171 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R172 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R173 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R174 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R175 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R176 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R177 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R179 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R180 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R182 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R185 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R186 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R188 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R190 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R191 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R193 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R195 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R196 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R197 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R198 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R199 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R201 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R211 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R212 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
C1 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C2 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C3 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C4 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C5 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C6 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C7 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C8 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C9 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C11 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C12 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C13 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C14 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C15 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C16 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C17 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C18 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C19 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C20 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C21 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C22 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C42 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C43 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C44 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C45 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C46 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C47 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C101 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C102 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C103 4030009110 S.CERAMIC C3216 JB 1C 474K-T-A
J1 6510020420 S.CONNECTOR S4B-PH-SM3-TB
J3 6510021990 S.CONNECTOR 10FMN-BMTTR-TBT
J4 6510021990 S.CONNECTOR 10FMN-BMTTR-TBT
J5 6510021990 S.CONNECTOR 10FMN-BMTTR-TBT
J6 6510021720 S.CONNECTOR 30FLT-SM1-TB
J7 6510021720 S.CONNECTOR 30FLT-SM1-TB
J9 6510022000 S.CONNECTOR 16FMN-BMTTR-TBT
DS1 5030001820 LCD A0087
DS70 5040002600 LED TLYU1002
DS71 5040002600 LED TLYU1002
DS72 5040002600 LED TLYU1002
DS73 5040002600 LED TLYU1002
DS74 5040002600 LED TLYU1002
DS75 5040002600 LED TLYU1002
DS76 5040002600 LED TLYU1002
DS77 5040002600 LED TLYU1002
DS78 5040002600 LED TLYU1002
DS79 5040002600 LED TLYU1002
DS80 5040002600 LED TLYU1002
DS81 5040002600 LED TLYU1002
DS82 5040002600 LED TLYU1002
DS83 5040002600 LED TLYU1002
DS84 5040002600 LED TLYU1002
DS85 5040002600 LED TLYU1002
DS86 5040002600 LED TLYU1002
DS87 5040002600 LED TLYU1002
DS88 5040002600 LED TLYU1002
DS89 5040002600 LED TLYU1002
DS90 5040002600 LED TLYU1002
W1 7030003860 S.JUMPER ERJ3GE JPW V
W41 7030003860 S.JUMPER ERJ3GE JPW V
W42 7030003860 S.JUMPER ERJ3GE JPW V
W70 7030003860 S.JUMPER ERJ3GE JPW V
W101 7030003860 S.JUMPER ERJ3GE JPW V
W102 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910052055 PCB B 5382E
EP2 6910012350 S.BEAD MMZ1608Y 102BT
EP40 6910012350 S.BEAD MMZ1608Y 102BT
EP45 6910012350 S.BEAD MMZ1608Y 102BT
EP46 6910012350 S.BEAD MMZ1608Y 102BT
EP70 8930051450 LCD CONTACT SRCN-2241-SP-N-W
EP152 6910012350 S.BEAD MMZ1608Y 102BT
EP155 6910012350 S.BEAD MMZ1608Y 102BT
EP157 6910012350 S.BEAD MMZ1608Y 102BT
EP159 6910012350 S.BEAD MMZ1608Y 102BT
6 - 2
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
