Icom IC-78 Service Manualvice Man

[PLL UNIT][MAIN UNIT]
S.=Surface mount
J4201 6510021720 S.CONNECTOR 30FLT-SM1-TB
J4401 6510021720 S.CONNECTOR 30FLT-SM1-TB
J4501 6450000140 CONNECTOR HSJ0807-01-010
J4502 6510018960 S.CONNECTOR B2B-PH-SM3-TB
J4651 6450001640 CONNECTOR TCS5044-01-4111
J4801 6450001130 CONNECTOR JPJ2042-01-110
J5001 6450000140 CONNECTOR HSJ0807-01-010
J5101 6450001790 CONNECTOR HLJ7000-01-3010
W801 7030003860 S.JUMPER ERJ3GE JPW V
W1202 7030003860 S.JUMPER ERJ3GE JPW V
W1311 7030003860 S.JUMPER ERJ3GE JPW V
W1726 7030003860 S.JUMPER ERJ3GE JPW V
W2101 7030003860 S.JUMPER ERJ3GE JPW V
W2201 7030003860 S.JUMPER ERJ3GE JPW V
W2351 7030003860 S.JUMPER ERJ3GE JPW V
W2603 7030003860 S.JUMPER ERJ3GE JPW V
W3601 7030003860 S.JUMPER ERJ3GE JPW V
W4216 7030003860 S.JUMPER ERJ3GE JPW V
W4401 7030003860 S.JUMPER ERJ3GE JPW V
W4801 7030003860 S.JUMPER ERJ3GE JPW V
W4802 7030003860 S.JUMPER ERJ3GE JPW V
W4803 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910052017 PCB B 5378G
EP4801 6910012350 S.BEAD MMZ1608Y 102BT
IC1 1180001070 S.IC TA7805F (TE16L)
IC2 1140004550 S.IC M65343FP/SC1287
IC6 1140007880 S.IC SC-1246A (TC190G08AF-0046-Z)
IC7 1130003610 S.IC TC4SU69F (TE85R)
Q9 1530002370 S.TRANSISTOR 2SC2714-O (TE85R)
Q10 1530002370 S.TRANSISTOR 2SC2714-O (TE85R)
Q11 1530002370 S.TRANSISTOR 2SC2714-O (TE85R)
Q12 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q18 1560000490 S.FET 2SK508 K52 T2B
Q26 1530002370 S.TRANSISTOR 2SC2714-O (TE85R)
Q28 1530002370 S.TRANSISTOR 2SC2714-O (TE85R)
Q29 1530002370 S.TRANSISTOR 2SC2714-O (TE85R)
Q30 1530002370 S.TRANSISTOR 2SC2714-O (TE85R)
Q32 1530002370 S.TRANSISTOR 2SC2714-O (TE85R)
Q33 1590000680 S.TRANSISTOR DTC114EUA T106
Q34 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q35 1530002060 S.TRANSISTOR 2SC4081 T107 R
D4 1720000390 S.VARICAP KV1470TL
D12 1750000020 S.DIODE 1SS184 (TE85R)
D15 1750000070 S.DIODE 1SS226 (TE85R)
D16 1790001250 S.DIODE MA2S111-(TX)
X1 6050007350 XTAL CR-337 (32.000 MHz)
L1 6200009300 S.COIL ELJPA 100KF 10U
L2 6200001830 S.COIL NL 322522T-100J
L3 6170000230 COIL LW-25
L4 6150004370 COIL LS-472C (C-15045)
L5 6200001830 S.COIL NL 322522T-100J
L6 6150004250 COIL LS-471A (C-14922)
L7 6150004250 COIL LS-471A (C-14922)
L8 6200001830 S.COIL NL 322522T-100J
L9 6200003960 S.COIL MLF1608A 1R0K-T
L10 6200003960 S.COIL MLF1608A 1R0K-T
L12 6200003260 S.COIL NL 322522T-101J
L14 6200003130 S.COIL NL 322522T-120J
L15 6200003140 S.COIL NL 322522T-150J
L19 6190001280 COIL E544GN-110248
L25 6200001830 S.COIL NL 322522T-100J
L26 6170000230 COIL LW-25
L27 6170000230 COIL LW-25
L30 6200001830 S.COIL NL 322522T-100J
L32 6200003050 S.COIL NL 322522T-R82J-3
L34 6200003430 S.COIL NL 322522T-R10J
L35 6200003420 S.COIL NL 322522T-R15J-3
L36 6200003430 S.COIL NL 322522T-R10J
L37 6200003450 S.COIL NL 322522T-082J
L38 6200001720 S.COIL NL 322522T-1R0J
L39 6200003050 S.COIL NL 322522T-R82J-3
L41 6200001830 S.COIL NL 322522T-100J
L42 6200003050 S.COIL NL 322522T-R82J-3
L44 6200003160 S.COIL NL 322522T-270J
L45 6200001710 S.COIL NL 322522T-220J
L46 6200003150 S.COIL NL 322522T-180J
L47 6200001830 S.COIL NL 322522T-100J
L48 6200003040 S.COIL NL 322522T-R68J-3
L49 6200004470 S.COIL MLF1608D R12K-T
L50 6200004470 S.COIL MLF1608D R12K-T
R2 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R3 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R4 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R5 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R6 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R7 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R8 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R9 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R10 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R12 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R13 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R14 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R15 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R16 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R17 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R18 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R19 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R20 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R21 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R22 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R23 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R24 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R25 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R26 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R27 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R28 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R29 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R30 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R31 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R32 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R33 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R34 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R35 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R36 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R37 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R38 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R39 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R40 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R41 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R42 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R43 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R44 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R49 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R51 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R52 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R53 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R57 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R74 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R75 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R78 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R84 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R85 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R87 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R88 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R89 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R90 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R91 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R93 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R94 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R95 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R96 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
6 - 10
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[PLL UNIT]
REF ORDER
DESCRIPTION
NO. NO.
