CLONING
15
8
Cloning allows you to quickly and easyly
transfer the programmed contents from
one transceiver to another transceiver, or,
data from PC to a transceiver using the optional EX-2119
cloning software.
D Transceiver to transceiver cloning
q Connect the OPC-474 CLONING CABLE with adapter plugs to
the [SP] jack of the master and slave transceivers.
• The master transceiver is used to send data to the slave trans-
ceiver.
w While pushing [Y] + [Z] + [V/M], turn power ON to enter
cloning mode (master transceiver only—power ON only for
slave transceiver).
•“CLonE” appears and the
transceivers enter the clone
standby condition.
e Push [PTT] on the master
transceiver.
•“CLoUt” appears in the mas-
ter transceiver’s display.
•“CL in” appears automati-
cally in the slave trans-
ceiver’s display.
e When cloning is finished, turn
power OFF, then ON again to
exit cloning mode.
D Cloning using PC
Data can be cloned to and from a PC (IBM compatible) using
the optional EX-2119
CLONING SOFTWARE and the optional OPC-
478
CLONING CABLE. Consult the EX-2119 CLONING SOFTWARE HELP
message for details.
D Cloning error
NOTE: DO NOT push [PTT] on the slave transceiver dur-
ing cloning. This will cause a cloning error.
When the display at right ap-
pears, a cloning error has oc-
curred.
In this case, both transceivers automatically return to the
clone standby condition and cloning must be repeated.
]
IC-A4#01 IM 01.12.5 5:14 PM Page 15 (1,1)
