SPECIFICATIONS
D General
• Frequency coverage : TX 118 to 136.975 MHz
RX 108 to 136.975 MHz
• Mode : AM (6K00A3E)
• Number of memory channels : 19
•Acceptable power supply : 9.6 V DC nominal
(negative ground) (authorized battery packs)
• Usable temp. range : –10˚C to +50˚C
• Frequency stability : ±10 ppm (0˚C to +50˚C)
• Current drain :
Tx 1.2 A (CW) max.
0.7 A (CW) typical
Rx 55 mA typical (at stand by)
250 mA max. (at AF max.)
• Antenna impedance : 50 Ω (nominal)
•Dimensions : 58(W)✕140.5(H)✕32.3(D) mm
(projections not incl.)
• Weight (with BP-195) : 425 g
D Transmitter
• Output power : 3.7 W (PEP) typical
1.0 W (CW) typical
• Modulation : Low level modulation
• Modulation limiting : 80 to 100 %
• Audio harmonic distortion : Less than 10 %
(at 60 % modulation)
• Hum and noise ratio : More than 35 dB
• Spurious emissions : More than 60 dB
D Receiver
• Receive system : Double conversion
superheterodyne
• Intermediate frequencies : 1st 28.95 MHz
2nd 450 kHz
•Sensitivity (with 50 Ω load) : 1 µV (at AM 6dB S/N)
• Squelch sensitivity : 1 µV
(with 50 Ω load)
• Selectivity : 8 kHz (at 6 dB)
25 kHz (at 60 dB)
• Spurious response : More than 60 dB
•Audio output power : 500 mW (at 10% distortion
(at 9.6 V DC) with an 8 Ω load)
• Noise and hum : More than 25 dB
• External SP connector : 3-conductor 3.5 (d) mm/8 Ω
All stated specifications are subject to change without
notice or obligation.
