5-2 INITIAL SET MODE
The following items can be adjusted via
Initial Set Mode
without opening the transceiver’s case.
■ ENTERING INITIAL SET MODE
1 Turn the transceiver power OFF.
2 While pushing and , turn power ON.
• Bank number appears regardless of the channel sepa-
ration type, ‘bank’ or ‘free’.
3 Push to cycle through the initial set mode items.
NOTE: Initial Set Mode access can be inhibited through
PC programming. In such case, cannot be used
and only ‘DISPLAY’ setting is available. Ask your Dealer
or Icom Service Center for PC programming.
ITEM
Display backlight
Display contrast
Squelch level
Minimum AF level
Link/unlink beep tones
with the volume control
Beep ON/OFF
Maximum beep level
DTCS balance
CTCSS/DTCS
Tone deviation
Maximum voice deviation
S-meter level
Transmit low power (L1)
Transmit low power (L2)
Transmit high power (H)
MODE
No.
NOTE
2 beeps: link 1 beep: unlink
2 beeps: ON 1 beep: OFF
Effective after exiting Initial Set Mode
Automatic transmission while pushing the key.
Automatic transmission while pushing the key.
Separate setting for CTCSS and DTCS
depending on the programmed tone system.
Automatic transmission while pushing the key.
Received signal level is shown in the display.
Automatic transmission while pushing the key.
Same as above.
Same as above.
METHOD
Push to select ‘bright’, ‘dark’ or ‘off’.
Rotate the volume control while pushing .
Rotate the volume control while pushing .
Rotate the volume control while pushing .
Push to select ‘link’ or ‘unlink’.
Push to turn beeps ON and OFF.
Rotate the volume control while pushing .
Rotate the volume control while pushing .
Rotate the volume control while pushing .
Rotate the volume control while pushing .
—
Rotate the volume control while pushing .
Rotate the volume control while pushing .
Rotate the volume control while pushing .
No.
ITEM
To Next Page
