Icom IC-F1610 Service Manual

[FRONT UNIT][FRONT UNIT]
IC1 1130009120 S.IC SED1526F0A
IC2 1140007630 S.IC HD64F3644H
IC3 1110003500 S.IC S-80742SL-A6-T1
IC4 1130005720 S.IC TC7W04F (TE12L)
IC5 1110003390 S.IC AN8005M-(E1)
Q1 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q2 1590001330 S.TRANSISTOR DTA114EUA T106
Q3 1590000680 S.TRANSISTOR DTC114EUA T106
Q4 1590001330 S.TRANSISTOR DTA114EUA T106
Q5 1590000680 S.TRANSISTOR DTC114EUA T106
Q6 1590000440 S.TRANSISTOR DTA143ZUA T106
Q7 1590000440 S.TRANSISTOR DTA143ZUA T106
Q8 1590000440 S.TRANSISTOR DTA143ZUA T106
Q9 1590000440 S.TRANSISTOR DTA143ZUA T106
Q10 1590000680 S.TRANSISTOR DTC114EUA T106
Q11 1590000680 S.TRANSISTOR DTC114EUA T106
D1 1790001280 S.DIODE MA111 (TX)
D2 1790001280 S.DIODE MA111 (TX)
D3 1790001280 S.DIODE MA111 (TX)
D4 1790001280 S.DIODE MA111 (TX)
D5 1750000130 S.DIODE DA204U T107
D6 1750000130 S.DIODE DA204U T107
D7 1750000130 S.DIODE DA204U T107
D8 1750000130 S.DIODE DA204U T107
D9 1750000130 S.DIODE DA204U T107
X1 6050009870 S.XTAL CR-567 (9.8304 MHz)
L1 6200001720 S.COIL NL 322522T-1R0J
R1 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 MΩ)
R2 7310002820 S.TRIMMER RV-158 (RH03A3AS5) 474
R3 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R4 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R5 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R6 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R7 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R8 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R9 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R10 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R11 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R12 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R13 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R15 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R16 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R17 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R18 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R19 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R20 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R21 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R22 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R23 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R24 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R25 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R26 7210002830 VARIABLE EVU-F2JFK4 B14
R27 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R28 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R29 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R30 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R31 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R32 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R34 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R35 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R36 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R37 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R38 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R39 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R40 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R41 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
S.=Surface mount
R42 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R43 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R44 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R45 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R46 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R47 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R48 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R49 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
C1 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C2 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C3 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C4 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C5 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C6 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C7 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C8 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C9 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C10 4030009000 S.CERAMIC C2012 JB 1C 224K-T-A
C11 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C13 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C14 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C16 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C17 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C18 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C19 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C20 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C21 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C22 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C23 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C24 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C25 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C26 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C28 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C29 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C30 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C31 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C32 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C33 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C34 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C35 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C36 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C37 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C38 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C39 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C40 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C41 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C42 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C43 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C44 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C45 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C46 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C47 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C48 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C49 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C50 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C51 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C52 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
J1 6450001470 CONNECTOR 95003-2881
J2 6510018030 S.CONNECTOR 53248-1217
DS1 5030001650 LCD LD-NU10377E
DS2 5040002470 S.LED FY1112H
DS3 5040002470 S.LED FY1112H
DS4 5040002470 S.LED FY1112H
DS5 5040002470 S.LED FY1112H
DS6 5040002470 S.LED FY1112H
DS7 5040002030 S.LED CL-170Y-CD-T
DS8 5040002030 S.LED CL-170Y-CD-T
DS10 5040002030 S.LED CL-170Y-CD-T
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
