9-4 CONNECTOR BOARD
•
TOP VIEW
D704
R701
MP701
9
1
PTT
MIC
TXD
RXD
RESET
MICE
OPTV
VCC
AFO
•
BOTTOM VIEW
C704
D705
C703
C702
C701
D703
D702
D701
EP704
B6035C
EP703EP702EP701
EP705
PTT
MIC
CLO
CLI
RES
GND
OPTV
AFO
VCC
9 - 6
