Icom IC-F50 Service Manual

[FRONT UNIT][FRONT UNIT]
IC401 1140011780 S.IC HD6432264F01TF (FX-2681A) T
IC403 1110005340 S.IC NJM12902V-TE1 T
IC405 1110001810 S.IC TA7368F (ER) T
IC406 1130011740 S.IC TC7W66FK (TE85L) T
IC407 1110005330 S.IC NJM12904V-TE1 T
IC408 1110006260 S.IC BD5242G-TR T
IC409 1130011580 S.IC 24LC64T-I/SN T
IC410 1130007570 S.IC BU4094BCFV-E2 T
Q401 1520000450 S.TRANSISTOR 2SB1132 T100 Q T
Q402 1590001190 S.TRANSISTOR XP6501-(TX) .AB T
Q403 1530002840 S.TRANSISTOR 2SC4116-Y (TE85R) B
Q404 1560001330 S.FET RSR025N03 B
Q405 1560001330 S.FET RSR025N03 B
Q406 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q407 1590000720 S.TRANSISTOR DTA144EUA T106 T
Q408 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q409 1590002370 S.TRANSISTOR XP4111 (TX) T
Q411 1590001660 S.TRANSISTOR XP4312 (TX) T
Q412 1590000720 S.TRANSISTOR DTA144EUA T106 T
Q413 1560001330 S.FET RSR025N03 B
D401 1790001250 S.DIODE MA2S111-(TX) T
D402 1790001250 S.DIODE MA2S111-(TX) T
D403 1790001250 S.DIODE MA2S111-(TX) T
D404 1790001260 S.DIODE MA2S077-(TX) T
D406 1790001250 S.DIODE MA2S111-(TX) T
X401 6050011720 S.XTAL CR-764 (19.6608 MHz) T
R401 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R402 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) T
R403 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R404 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R405 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ) T
R406 7030005210 S.RESISTOR ERJ2GEJ 822 X (8.2 kΩ) T
R407 7030005230 S.RESISTOR ERJ2GEJ 334 X (330 kΩ) T
R408 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R409 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R410 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R411 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R412 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R413 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ) T
R414 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ) T
R415 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) T
R416 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) T
R417 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) T
R418 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) T
R420 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ) T
R421 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R422 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R423 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R426 7030005230 S.RESISTOR ERJ2GEJ 334 X (330 kΩ) T
R427 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R428 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R429 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R430 7030007350 S.RESISTOR ERJ2GEJ 393 X (39 kΩ) T
R432 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ) T
R433 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R434 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) B
R435 7030007260 S.RESISTOR ERJ2GEJ 330 X (33 Ω) T
R436 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) T
R437 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R438 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ) T
R439 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ) T
R440 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R441 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) T
R442 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
R443 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
R444 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R445 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R446 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R455 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) T
R456 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) T
R457 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) B
R458 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R461 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ) T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
R462 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ) T
R463 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R464 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R465 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R466 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R467 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R468 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R469 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R470 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R471 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ) T
R472 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R473 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R474 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R475 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R476 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) T
R477 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) T
R478 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) T
R479 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) T
R480 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) T
R482 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R483 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R484 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R485 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R486 7410001130 S.ARRAY EXB28V102JX T
R487 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R488 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R489 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R490 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R491 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) T
R492 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) T
R493 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) T
R494 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) T
R495 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) T
R496 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R497 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R500 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R501 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R502 7030010080 S.RESISTOR ERJ2RHD 104 X (100 kΩ) T
R503 7030010080 S.RESISTOR ERJ2RHD 104 X (100 kΩ) T
R506 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ) T
R507 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ) T
R508 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ) T
R509 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R511 7030005700 S.RESISTOR ERJ2GEJ 274 X (270 kΩ) T
R512 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R513 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ) T
R514 7030010040 S.RESISTOR ERJ2GE-JPW T
C401 4030017460 S.CERAMIC ECJ0EB1E102K T
C402 4030017460 S.CERAMIC ECJ0EB1E102K T
C403 4030017460 S.CERAMIC ECJ0EB1E102K T
C404 4030017460 S.CERAMIC ECJ0EB1E102K T
C405 4030017760 S.CERAMIC ECJ0EB1H222K T
C406 4030018110 S.CERAMIC ECJ0EB1H272K T
C407 4030017430 S.CERAMIC ECJ0EC1H101J T
C408 4030016930 S.CERAMIC ECJ0EB1A104K T
C409 4030016930 S.CERAMIC ECJ0EB1A104K T
C410 4030016930 S.CERAMIC ECJ0EB1A104K T
C411 4030016930 S.CERAMIC ECJ0EB1A104K T
C412 4030016930 S.CERAMIC ECJ0EB1A104K T
C413 4030016930 S.CERAMIC ECJ0EB1A104K T
C414 4030017640 S.CERAMIC ECJ0EC1H150J T
C415 4030016790 S.CERAMIC ECJ0EB1C103K T
C416 4030017630 S.CERAMIC ECJ0EC1H120J T
C417 4030017580 S.CERAMIC ECJ0EC1H060C T
C418 4030016930 S.CERAMIC ECJ0EB1A104K T
C419 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C420 4030016930 S.CERAMIC ECJ0EB1A104K T
C421 4030016930 S.CERAMIC ECJ0EB1A104K T
C423 4030016930 S.CERAMIC ECJ0EB1A104K T
C424 4030017460 S.CERAMIC ECJ0EB1E102K T
C425 4030017730 S.CERAMIC ECJ0EB1E471K T
C426 4030017460 S.CERAMIC ECJ0EB1E102K B
C427 4550006080 S.TANTALUM TEESVB2 1C 106M8L T
C428 4030016930 S.CERAMIC ECJ0EB1A104K T
C429 4030017460 S.CERAMIC ECJ0EB1E102K T
C430 4030017460 S.CERAMIC ECJ0EB1E102K T
C431 4030016930 S.CERAMIC ECJ0EB1A104K T
C432 4030017460 S.CERAMIC ECJ0EB1E102K T
C433 4030017420 S.CERAMIC ECJ0EC1H470J B
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
A: The scrambler IC is installed type. B: The scrambler IC is not installed type.
C: High-band. D: Low-band. E: Intrinsically safe version.
