CONNECTION AND INSTALLATION
New2001
5
■ Rear panel description and connections
Optional speaker
(SP-22)
q Antenna
r
t Optional cable
(OPC-617/822) e 12 V
Battery
Black: _
Red: +
w
Crimp
Solder
NOTE: Use the ter-
minals for the cable
connection.
NEVER connect to
a 24 V battery. This
could damage the
transceiver.
