6 - 1
SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[FRONT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1130010800 S.IC LC75824W B 80.9/24.4
IC2 1130008560 S.IC TC75S51F (TE85L) B 25.4/22.7
Q1 1590000720 S.TR DTA144EUA T106 B 52.8/22.4
Q2 1590000430 S.TR DTC144EUA T106 B 55.8/22.3
Q3 1590000430 S.TR DTC144EUA T106 B 55.9/25.4
Q4 1590000720 S.TR DTA144EUA T106 B 52.8/25.5
D1 1790001670 S.DIO RB706F-40T106 T 9.8/6.4
D2 1790001670 S.DIO RB706F-40T106 B 11/27.2
D3 1790001670 S.DIO RB706F-40T106 B 16.1/21.2
D4 1790001250 S.DIO MA2S111-(TX) B 56.6/17.4
D5 1790001250 S.DIO MA2S111-(TX) B 62.1/18
D6 1790001250 S.DIO MA2S111-(TX) B 62.7/15
L1 6200003960 S.COL MLF1608A 1R0K-T T 13.7/17.6
R1 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 7.1/17.6
R2 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 15.5/18.2
R3 7030003390 S.RES ERJ3GEYJ 391 V (390
Ω
) B 48.1/21
R4 7030003390 S.RES ERJ3GEYJ 391 V (390
Ω
) B 101.6/21.2
R5 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 31.4/23.2
R6 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 65.9/5.5
R7 7030000330 S.RES MCR10EZHJ 390
Ω
(391) B 53.4/20.2
R8 7410000950 S.ARY EXB-V8V 102JV B 72.6/20.5
R9 7410000770 S.ARY EXB-V4V 102JV (1 k
Ω
) B 54.8/27.8
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 18.1/18.2
R11 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 11/25.3
R12 7210003020 VAR EVU-F2KFK1 B14 (10KB)
R13 7030003730 S.RES ERJ3GEYJ 274 V (270 k
Ω
) B 76.5/14
R14 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 11.8/6.4
R16 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 32.3/10.1
R17 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 82.3/14
R18 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 80.3/16
R19 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 78.4/14
R20 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 21.7/20.4
R21 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 23/23.2
R22 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 28.5/20.2
R23 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 25.8/20.2
R24 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 19.8/25.5
R25 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 18.2/20
C1 4030007090 S.CER C1608 CH 1H 470J-T B 69.6/30.3
C2 4030007090 S.CER C1608 CH 1H 470J-T B 68.3/30.3
C3 4030007090 S.CER C1608 CH 1H 470J-T B 67/30.3
C4 4030007090 S.CER C1608 CH 1H 470J-T B 65.7/30.3
C5 4030007090 S.CER C1608 CH 1H 470J-T B 64.4/30.3
C6 4030007090 S.CER C1608 CH 1H 470J-T B 63.1/30.3
C7 4030007090 S.CER C1608 CH 1H 470J-T B 61.8/30.3
C8 4030007090 S.CER C1608 CH 1H 470J-T B 60.5/30.3
C9 4030007090 S.CER C1608 CH 1H 470J-T B 59.2/30.3
C10 4030007090 S.CER C1608 CH 1H 470J-T B 59.5/21.5
C11 4030007090 S.CER C1608 CH 1H 470J-T B 60.8/21.5
C12 4030007090 S.CER C1608 CH 1H 470J-T B 62.1/21.5
C13 4030007090 S.CER C1608 CH 1H 470J-T B 63.4/21.5
C14 4030007090 S.CER C1608 CH 1H 470J-T B 64.7/21.5
C15 4030007090 S.CER C1608 CH 1H 470J-T B 66/21.5
C16 4030007090 S.CER C1608 CH 1H 470J-T B 67.3/21.5
C17 4030007090 S.CER C1608 CH 1H 470J-T B 68.6/21.5
C18 4030007090 S.CER C1608 CH 1H 470J-T B 16.8/18.2
C19 4030006860 S.CER C1608 JB 1H 102K-T T 16.3/17.6
C20 4030007090 S.CER C1608 CH 1H 470J-T B 9.3/17.2
C21 4030007090 S.CER C1608 CH 1H 470J-T B 9/9.9
C22 4030007090 S.CER C1608 CH 1H 470J-T T 4.5/17.6
C23 4030007090 S.CER C1608 CH 1H 470J-T B 6.5/9.9
C24 4030007090 S.CER C1608 CH 1H 470J-T B 72.1/5.5
C25 4030007090 S.CER C1608 CH 1H 470J-T B 90.8/7.4
C26 4030007090 S.CER C1608 CH 1H 470J-T B 122.6/25.6
C27 4030007090 S.CER C1608 CH 1H 470J-T B 122.6/30.4
C28 4030007090 S.CER C1608 CH 1H 470J-T B 122.6/15.6
C29 4030007090 S.CER C1608 CH 1H 470J-T B 110.6/2.8
C30 4030011600 S.CER C1608 JB 1E 104K-T B 79.7/14
C31 4030011600 S.CER C1608 JB 1E 104K-T B 83.6/14
C32 4030011600 S.CER C1608 JB 1E 104K-T B 81/14
C33 4030007130 S.CER C1608 CH 1H 101J-T B 76.5/15.3
C34 4030007090 S.CER C1608 CH 1H 470J-T B 29.5/10.1
C35 4030007090 S.CER C1608 CH 1H 470J-T B 70.9/30.3
C37 4550000550 S.TAN TEESVA 1V 224M8L B 19.8/22.1
C39 4030006900 S.CER C1608 JB 1H 103K-T B 27.8/24.2
C40 4550005980 S.TAN TEESVA 1A 475M8L B 20.8/28.6
C41 4030006860 S.CER C1608 JB 1H 102K-T B 19/27.4
J1 6450002210 CNR 3017-8821 <KIN>
J2 6510023090 S.CNR 20FLT-SM1-TB B 64.5/25.9
DS1 5040002310 S.LED SML-311YTT86 T 46.1/22.8
DS2 5040002310 S.LED SML-311YTT86 T 57.7/22.8
DS3 5040002310 S.LED SML-311YTT86 T 69.3/22.8
DS4 5040002310 S.LED SML-311YTT86 T 104.1/22.8
DS5 5040002310 S.LED SML-311YTT86 T 92.5/22.8
DS6 5040002310 S.LED SML-311YTT86 T 81/22.8
DS7 5040002310 S.LED SML-311YTT86 T 28.2/23.2
DS8 5040002310 S.LED SML-311YTT86 T 35/5.3
DS9 5040002310 S.LED SML-311YTT86 T 66.5/4.7
DS10 5040002310 S.LED SML-311YTT86 T 100.5/4.7
DS11 5040002310 S.LED SML-311YTT86 T 122/23.2
DS12 5030002780
W1 8900010950 CBL OPC-1126 (P=0.5 N=20 L=90)
EP2 8930057820 LCT SRCN-2526-SP-N-W
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1110003490 S.IC TA31136FN (D,EL) T 101.7/49.9
IC2 1110002750 S.IC TA75S01F (TE85R) T 56/67.2
IC3 1150002041 IC RA30H1317M-21 [25W]
1150002071 IC RA60H1317M-21 [50W]
IC4 1130010860 S.IC TB31256FL (EB) T 82.1/39.4
IC5 1110005330 S.IC NJM12904V-TE1 T 82.7/21.9
IC6 1190001350 S.IC M62364FP 600D T 103.2/29.5
IC7 1190001340 S.IC M62334FP 600C T 81.4/61.1
IC8 1110003090 IC LA4425A
IC9 1180001250 S.IC TA7808F (TE16L) T 21.4/71.1
IC10 1180000970 S.IC AN78L05M-(E1) B 49.7/74
IC11 1130008560 S.IC TC75S51F (TE85L) B 106.6/40.7
IC14 1130009330 S.IC TC35453F (BR,DRY) B 108.1/11.6
IC15 1130006220 S.IC TC4W53FU (TE12L) B 113.5/21.7
IC18 1110002750 S.IC TA75S01F (TE85R) B 18.1/57.2
IC19 1130009700 S.IC LC73872M-TRM B 93.2/9
IC20 1140010190 S.IC HD64F2268TF20 B 44.1/34.4
IC21 1110005340 S.IC NJM12902V-TE1 B 101.4/27.6
IC22 1130004200 S.IC TC4S66F (TE85R) B 82.9/22.6
IC23 1140009240 S.IC HN58X24128FPI T 60.3/10.3
IC24 1110005770 S.IC S-80942CNMC-G9C-T2 T 46.2/45.8
IC25 1130004200 S.IC TC4S66F (TE85R) B 23.4/50.8
IC26 1180002400 S.REG S-812C30AMC-C2K-T2 T 86.4/32.1
Q1 1560000840 S.FET 2SK1829 (TE85R) T 92.5/52.3
Q2 1580000730 S.FET 3SK293 (TE85L) B 90.4/53.1
Q3 1580000660 S.FET 3SK272-(TX) B 78.3/52.5
Q4 1530002600 S.TR 2SC4215-O (TE85R) B 93.2/48.6
Q5 1530002850 S.TR 2SC4116-BL (TE85R) T 97.7/55.3
Q6 1590000720 S.TR DTA144EUA T106 B 92.7/32.6
Q8 1530002620 S.TR 2SC3585-T1B R (R44) B 47.3/62.9
Q9 1530003310 S.TR 2SC5107-O (TE85R) B 52.5/62
Q10 1530003310 S.TR 2SC5107-O (TE85R) T 59.8/43.1
Q11 1530003310 S.TR 2SC5107-O (TE85R) T 66.7/42
Q12 1530003310 S.TR 2SC5107-O (TE85R) T 69.9/41.7
Q13 1530002920 S.TR 2SC4226-T1 R25 T 71.7/36.5
Q14 1530002920 S.TR 2SC4226-T1 R25 T 63.2/36.6
Q15 1590001400 S.TR XP1214 (TX) B 68.6/35
Q16 1590000430 S.TR DTC144EUA T106 B 65.4/32.6
Q17 1530002850 S.TR 2SC4116-BL (TE85R) B 55.7/47.2
Q18 1560000540 S.FET 2SK880-Y (TE85R) B 75.6/27.7
Q19 1530002600 S.TR 2SC4215-O (TE85R) B 96.3/42.2
Q20 1530003090 S.TR 2SC4213-B (TE85R) B 114.1/25
Q21 1530002850 S.TR 2SC4116-BL (TE85R) T 114.3/22.9
Q22 1590000430 S.TR DTC144EUA T106 B 92.4/29.9
Q23 1550000020 S.FET 2SJ377 (TE16L) T 10/70.3
