S.=Surface mount
6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q24 1590000430 S.TR DTC144EUA T106 T 16.7/68.4
Q25 1540000550 S.TR 2SD1664 T100Q B 26.2/58.6
Q26 1540000550 S.TR 2SD1664 T100Q B 31.2/58.6
Q27 1520000460 S.TR 2SB1132 T100 R B 36.2/58.6
Q28 1590001190 S.TR XP6501-(TX) .AB B 39.2/61.9
Q29 1590000430 S.TR DTC144EUA T106 T 26.5/56.9
Q30 1590000430 S.TR DTC144EUA T106 T 34.7/56.3
Q31 1590001450 S.FET 2SJ144-GR (TE85R) B 13.7/28.7
Q32 1590000430 S.TR DTC144EUA T106 B 11.4/16.6
Q33 1590000430 S.TR DTC144EUA T106 B 11.1/13.9
Q34 1530002850 S.TR 2SC4116-BL (TE85R) T 100.4/41.4
Q35 1590001400 S.TR XP1214 (TX) T 84.7/27.1
Q36 1530002850 S.TR 2SC4116-BL (TE85R) T 113.5/37.4
Q37 1530002850 S.TR 2SC4116-BL (TE85R) T 89.4/15.8
Q38 1590000430 S.TR DTC144EUA T106 T 92/18.2
Q39 1590000990 S.TR DTC363EK T146 B 12/56.2
Q40 1590000430 S.TR DTC144EUA T106 B 12.9/50.6
Q41 1590000720 S.TR DTA144EUA T106 T 40.6/43.8
Q42 1590000430 S.TR DTC144EUA T106 T 37.9/45.2
Q43 1590000430 S.TR DTC144EUA T106 B 85.3/6.7
Q44 1590000430 S.TR DTC144EUA T106 T 47.2/27.5
Q48 1590000430 S.TR DTC144EUA T106 B 3.5/18.6
Q49 1590000430 S.TR DTC144EUA T106 B 25.7/47.8
Q50 1530002060 S.TR 2SC4081 T106 R B 83.7/39.6
Q51 1510000510 S.TR 2SA1576A T106R B 80.1/40
Q52 1530002850 S.TR 2SC4116-BL (TE85R) B 75.9/37
Q53 1530002850 S.TR 2SC4116-BL (TE85R) B 75.4/34.5
Q54 1590003090 S.TR XP2401-(TX) B 84.6/42.9
Q55 1590003100 S.TR XP2501-(TX) B 80.6/42.9
Q56 1590000430 S.TR DTC144EUA T106 B 20.9/46.2
Q57 1530002850 S.TR 2SC4116-BL (TE85R) [50W] T 57.7/63.7
1590001050 S.TR DTC114TUA T106 [25W} T 57.7/63.7
D1 1790001210 S.DIO 1SS375-TL B 115.6/88.8
D2 1750000510 S.DIO UM9401F [25W] only T 99.7/69.6
D3 1710001060 DIO XB15A407 [50W] only
D4 1750000710 S.VCP HVC350BTRF B 91.2/56.9
D5 1750000510 S.DIO UM9401F T 95.7/65.6
D6 1790000620 S.DIO MA77 (TX) T 88/63.8
D7 1790001240 S.DIO MA2S728-(TX) B 91.4/64.6
D8 1750000710 S.VCP HVC350BTRF B 94.7/59.4
D9 1750000710 S.VCP HVC350BTRF B 85.9/57.3
D10 1750000710 S.VCP HVC350BTRF B 83.5/56.1
D11 1790001210 S.DIO 1SS375-TL B 108.2/73.9
D14 1790000620 S.DIO MA77 (TX) B 56.9/54.9
D15 1790000620 S.DIO MA77 (TX) B 61.9/48.2
D16 1750000710 S.VCP HVC350BTRF T 74.2/24.4
D17 1750000710 S.VCP HVC350BTRF T 65.5/24.4
D18 1720000400 S.VCP 1SV245 (TPH3) T 60.3/24.4
D19 1790001250 S.DIO MA2S111-(TX) B 55.8/50.4
D20 1790001250 S.DIO MA2S111-(TX) B 94.3/37
D21 1750000830 S.VCP HVC362TRF B 104.2/37.8
D22 1790000700 DIO DSA3A1
D23 1750000370 S.DIO DA221 TL B 25.8/63.4
D24 1750000370 S.DIO DA221 TL B 30.8/63.4
D25 1790001250 S.DIO MA2S111-(TX) T 94.5/53.9
D26 1790001250 S.DIO MA2S111-(TX) B 11.9/30.6
D27 1790000620 S.DIO MA77 (TX) T 49.4/38.9
D28 1160000070 S.DIO DAN202K T146 T 34.1/40.6
D31 1160000070 S.DIO DAN202K T146 B 13.5/47.5
D32 1790001240 S.DIO MA2S728-(TX) T 57/72.8
D34 1790001250 S.DIO MA2S111-(TX) T 49.8/8
D35 1790001250 S.DIO MA2S111-(TX) B 12.9/53.3
D50 1750000710 S.VCP HVC350BTRF T 72.7/24.4
D51 1750000710 S.VCP HVC350BTRF T 72.7/27
D52 1750000710 S.VCP HVC350BTRF T 74.2/27
D53 1750000710 S.VCP HVC350BTRF T 66.9/24.4
D54 1750000710 S.VCP HVC350BTRF T 66.9/27
D55 1750000710 S.VCP HVC350BTRF T 65.5/27
D56 1790001250 S.DIO MA2S111-(TX) T 61.3/63.7
D58 1790001240 S.DIO MA2S728-(TX) T 85.9/37.4
D59 1790001240 S.DIO MA2S728-(TX) T 87.2/37.4
D60 1790001240 S.DIO MA2S728-(TX) T 87.2/39.9
D61 1790001240 S.DIO MA2S728-(TX) T 87/41.6
D63 1160000070 S.DIO DAN202K T146 T 37.2/19
D65 1160000070 S.DIO DAN202K T146 T 36.8/22.5
D67 1160000070 S.DIO DAN202K T146 T 44.3/27.5
D68 1750000150 S.DIO DA204K T146 T 91.4/55.1
D69 1790001240 S.DIO MA2S728-(TX) B 76.3/24.1
D70 1790001250 S.DIO MA2S111-(TX) B 112.9/42.5
D71 1750000520 S.DIO DAN222TL T 46.1/70.8
D72 1750000350 S.DIO 1SV252 (TE85L) T 40.3/66.6
FI1 2030000150 S.MLH FL-335 (46.350 MHz) T 86.2/46.6
FI2 2020001410 CER CFWLB450KGFA-B0 [M/N]
2020001840 CER ALFYM450F=K [W/N]
FI3 2040001440 S.LC NFE31PT152Z1E9L B 65.3/70
FI4 2040001440 S.LC NFE31PT152Z1E9L B 65.3/66.7
FI5 2040001440 S.LC NFE31PT152Z1E9L [50W] only B 65.3/63.4
X1 6070000190 S.DCR CDBCB450KCAY24-R0 T 104.1/57.4
X2 6050011070 S.XTL CR-664A (15.300 MHz) B 98.7/37.5
X3 6050009910 S.XTL CR-563 (3.579545 MHz) T 108.7/10.9
X4 6050009520 S.XTL CR-520 (19.6608 MHz) T 44.1/34.4
L1 6110001670 COL LA-253
L2 6110001600 COL LA-243
L3 6110001670 COL LA-253
L4 6200008150 S.COL 0.35-1.6-7TL 44N T 99.6/66.6
L5 6170000230 COL LW-25
L6 6200008150 S.COL 0.35-1.6-7TL 44N T 92.7/64.9
L7 6200008260 S.COL 0.30-1.7-8TL 60N T 95.9/58.7
L8 6200007750 S.COL LQW2BHN56NJ01L T 93.5/58.5
L9 6200004660 S.COL MLF1608A 1R8K-T T 86.1/55
L11 6200008090 S.COL LQW2BHN68NJ01L T 82.4/55
L12 6200009180 S.COL ELJRE R10J-F3 B 76.4/53.6
L13 6200003330 S.COL NL 322522T-1R0J-3 B 81.5/49.4
L16 6110001670 COL LA-253
L18 6200005740 S.COL ELJRE 47NG-F [25W] T 43/66.2
6200007000 S.COL ELJRE 82NG-F [50W] T 43/66.2
L19 6200009570 S.COL ELJRE R12G-F3 B 45.1/62.2
L20 6200009530 S.COL ELJRE R15G-F3 B 51.8/60.1
L21 6200009530 S.COL ELJRE R15G-F3 T 59.7/45
L23 6200002000 S.COL NL 252018T-3R3J B 64.9/35.2
L24 6200002000 S.COL NL 252018T-3R3J B 71.9/38.9
L25 6200009460 S.COL 0.25-1.9-7TL 67N T 71.2/30.7
L26 6200009460 S.COL 0.25-1.9-7TL 67N T 61.8/30.8
L27 6200002610 S.COL NL 252018T-R47J B 72.9/27.8
L28 6200002610 S.COL NL 252018T-R47J B 66.2/27.8
L29 6200004660 S.COL MLF1608A 1R8K-T T 85/35.6
L31 6200007750 S.COL LQW2BHN56NJ01L B 98.9/62.1
L32 6200005720 S.COL ELJRE 33NG-F T 74.9/43
L33 6200002850 S.COL NL 252018T-R82J T 105.3/44.1
L35 6200002840 S.COL NL 252018T-R22J T 97.8/43.2
L36 6200002860 S.COL NL 252018T-4R7J T 49.1/46
L37 6200003960 S.COL MLF1608A 1R0K-T T 43/67.5
L50 6200008150 S.COL 0.35-1.6-7TL 44N T 71.7/21.6
L51 6200009460 S.COL 0.25-1.9-7TL 67N T 66.2/21.3
L52 6200006670 S.COL ELJRE 68NG-F T 66.7/44.8
L53 6200004660 S.COL MLF1608A 1R8K-T T 110.8/38.8
L54 6200007750 S.COL LQW2BHN56NJ01L B 86.5/50.1
L55 6200006980 S.COL ELJRE R10G-F T 71.8/42.9
R1 7030000620 S.RES MCR10EZHJ 100 k
Ω
B 107.3/98.2
R2 7030000220 S.RES MCR10EZHJ 47
Ω
(470) B 102.5/87.9
R3 7030000220 S.RES MCR10EZHJ 47
Ω
(470) B 119.5/75.1
R4 7030003370 S.RES ERJ3GEYJ 271 V (270
Ω
) B 113.1/88.3
R5 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) [25W] B 116.9/91.5
7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) [50W] B 116.9/91.5
R6 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) [25W] B 103.9/75.9
7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) [50W] B 103.9/75.9
R7 7030003370 S.RES ERJ3GEYJ 271 V (270
Ω
) B 110.7/73
R8 7030001170 S.RES MCR50JZHJ 220
Ω
(221) B 83.5/67.1
R9 7030001170 S.RES MCR50JZHJ 220
Ω
(221) B 83.5/64.1
R10 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 94.4/48.2
R11 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 93.4/59.3
R12 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 91.5/61.1
R13 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 89.9/56.9
R14 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 88.8/59.6
R15 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) B 93.1/53.5
R16 7030003370 S.RES ERJ3GEYJ 271 V (270
Ω
) B 87.7/56.3
R18 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 89.7/52.7
R19 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 92.3/51.6
R20 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 84.4/55
R21 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 84.6/58
R22 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 83.8/59.9
R23 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) B 83.3/58
R24 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 80.1/58.8
R25 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 80.8/54.7
R26 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 69.2/47.4
R27 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 71.7/51.8
R28 7030003210 S.RES ERJ3GEYJ 120 V (12
Ω
) B 71/48.6
R29 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 75.8/51.6
R30 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 82.1/47.2
R31 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 84.6/51.4
R32 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) T 79.7/47.1
R33 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 89.7/45.9
R34 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) B 93/46.7
R35 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 94.2/51.8
R36 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 108.2/53.4
R37 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) [W/N] T 95.8/53.7
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) [M/N] T 95.8/53.7
R38 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 100.1/47.5
R39 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 101.5/45.1
R40 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 103/46.4
R41 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 98.3/55.7
R42 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 99.8/57.5
R43 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 99.8/53.7
R44 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 103.7/52
R45 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) B 103.7/55.4
R46 7030003410 S.RES ERJ3GEYJ 561 V (560
Ω
) B 107/54.6
