6 - 1
SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[FRONT UNIT]
IC1 1110006440 S.IC M62320FP DF5J B 20.7/73.6
IC2 1110006440 S.IC M62320FP DF5J B 20.7/62.5
IC101 1180002400 S.REG S-812C30AMC-C2K-T2 B 9.4/80.8
IC201 1110001810 S.IC TA7368F (ER) B 28.5/47.4
IC203 1110005340 S.IC NJM12902V-TE1 B 8.2/68
IC204 1130004200 S.IC TC4S66F (TE85R) B 7.6/75.9
IC205 1130004200 S.IC TC4S66F (TE85R) B 34/56.1
Q1 1590000980 S.TR DTB123EK T146 B 34.6/94.7
Q2 1590000980 S.TR DTB123EK T146 B 34.4/98.3
Q102 1590001940 S.TR DTC144EE TL B 26.2/72.9
Q103 1590000980 S.TR DTB123EK T146 B 12.7/76.7
Q104 1590000980 S.TR DTB123EK T146 B 28.2/35.7
Q201 1590002230 S.TR UMG2N TL B 14/55
Q202 1520000450 S.TR 2SB1132 T100 Q B 35.4/37.3
Q203 1590001190 S.TR XP6501-(TX) AB B 29.9/42.1
Q206 1590002430 S.TR DTA144EE TL B 14/50.9
Q207 1590000430 S.TR DTC144EUA T106 B 37.1/96.5
Q208 1530002840 S.TR 2SC4116-Y (TE85R) B 41.4/113
Q209 1560001330 S.FET RSR025N03 B 41.1/109.5
Q210 1560001330 S.FET RSR025N03 B 41.1/105.4
D1 1730002530 S.ZEN NNCD6.2G-T1 B 25.2/81.6
D101 1160000140 S.DIO DAP222 TL B 15.3/47.1
D102 1160000140 S.DIO DAP222 TL B 15.3/45
D201 1790001250 S.DIO MA2S111-(TX) B 17.2/49
D202 1790001250 S.DIO MA2S111-(TX) B 10.9/71.5
D203 1790001250 S.DIO MA2S111-(TX) B 36.2/54.2
D204 1790001250 S.DIO MA2S111-(TX) B 12.3/50.9
D205 1790001250 S.DIO MA2S111-(TX) B 14.9/52.7
L1 6200004720 S.COL MLF1608D R10K-T B 30.3/87.8
L2 6200004720 S.COL MLF1608D R10K-T B 28.9/88.5
L3 6200004720 S.COL MLF1608D R10K-T B 26.3/87.1
L4 6200004720 S.COL MLF1608D R10K-T B 21.6/89.7
L5 6200004720 S.COL MLF1608D R10K-T B 25.1/88.1
L6 6200004720 S.COL MLF1608D R10K-T B 31.2/90.2
L7 6200004720 S.COL MLF1608D R10K-T B 23.9/86.1
R1 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 34.8/127
R2 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) T 34.8/126.1
R3 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 36.5/93.5
R4 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 26.1/77
R5 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 26.1/75.8
R6 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 25.7/67
R7 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 25.8/65.1
R11 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 21.3/86.2
R12 7030001090 S.RES MCR50JZHJ 47
Ω
(470) B 33.7/83.9
R13 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 27.5/87.1
R15 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 22.8/86.3
R16 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 28.2/85
R30 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 40.7/74.4
R31 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 40.7/75.3
R32 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 40.7/76.2
R33 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 40.5/77.1
R34 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 17.2/89.4
R35 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 18.1/89.3
R36 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 19/89.3
R37 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 19.9/89.3
R38 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 40.7/65.6
R40 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 40.7/72.5
R50 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
)
[F80DT/T] only B 16.4/79.1
R51 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
)
[F80DS/S] only B 17/80.6
R101 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 12.6/78.9
R102 7030008370 S.RES ERJ2GEJ 561 X (560
Ω
) B 11.1/78.3
R103 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 18.2/33.6
R104 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 15.4/57.1
R105 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) B 9.1/93.2
R106 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) B 10/93.2
R107 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 14.1/57.9
R108 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 14.8/60.7
R109 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 15.2/62.5
R110 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 26.6/58.8
R111 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 26.6/59.7
R112 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 26.6/60.6
R113 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 26.6/61.5
R115 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 12.8/94.2
R116 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 40/67.7
R201 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 17.6/55
R202 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 16.3/54.2
R203 7030003830 S.RES ERJ3GEYJ 185 V (1.8 M
Ω
) B 26.8/71.1
R204 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 15.5/48.9
R205 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 14.5/49.2
R207 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 11.8/63.6
R208 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) B 12.6/69.7
R209 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 13.8/68.6
R210 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 13.8/66.8
R211 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 13.8/69.5
R212 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B Mar-69
R213 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 31.5/57.4
R214 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 36.2/56.3
R215 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 27.2/42.1
R216 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 13.6/49.2
R217 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 10.2/64.5
R219 7030003860 S.RES ERJ3GE JPW V B 7.3/64.3
R221 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 6.4/63.2
R222 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) B 34.5/51
R223 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 3/69.9
R224 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 2.8/67.1
R225 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) B 30.2/43.9
R226 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 27.2/43.9
R227 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 16.7/51.2
R228 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) B 5.1/64.9
R229 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 9.3/72.6
R231 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 3/68.1
R232 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 7.6/72.6
R235 7030007260 S.RES ERJ2GEJ 330 X (33
Ω
) B 27.6/51.9
R236 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 27.6/51
R237 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 5.6/78.2
R238 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 6/79.4
R239 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 36.5/99.3
R240 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 38.5/98.7
R241 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 36.9/98.4
R242 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 41.9/114.9
R250 7030003860 S.RES ERJ3GE JPW V B 27.2/68.1
R251 7030003860 S.RES ERJ3GE JPW V B 40.2/78.8
R259 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 16.6/87.8
R260 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 15.7/87.8
R261 7030003860 S.RES ERJ3GE JPW V B 41.3/71.5
R262 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 16.7/53
R263 7030010040 S.RES ERJ2GE-JPW B 40.5/46
R264 7030010040 S.RES ERJ2GE-JPW B 40.5/40
R265 7030010040 S.RES ERJ2GE-JPW B 40.5/34
R266 7030010040 S.RES ERJ2GE-JPW B 40.5/28
R267 7030010040 S.RES ERJ2GE-JPW B 40.5/22
R268 7030010040 S.RES ERJ2GE-JPW B 40.5/15.9
R269 7030010040 S.RES ERJ2GE-JPW B 40.5/10
R270 7030010040 S.RES ERJ2GE-JPW B 40.5/4
R271 7030010040 S.RES ERJ2GE-JPW B 5.4/46
R272 7030010040 S.RES ERJ2GE-JPW B 5.4/40
R273 7030010040 S.RES ERJ2GE-JPW B 5.4/34
R274 7030010040 S.RES ERJ2GE-JPW B 5.5/28
R275 7030010040 S.RES ERJ2GE-JPW B 5.5/16
R276 7030010040 S.RES ERJ2GE-JPW B 5.5/4
R277 7030010040 S.RES ERJ2GE-JPW B 5.5/10
R278 7030010040 S.RES ERJ2GE-JPW B 5.5/22
C2 4030016790 S.CER ECJ0EB1C103K B 21.3/87.6
C3 4030017460 S.CER ECJ0EB1E102K B 17.1/86.6
C4 4030016930 S.CER ECJ0EB1A104K B 15.3/75.2
C5 4030016930 S.CER ECJ0EB1A104K B 15.2/64.3
C6 4030017460 S.CER ECJ0EB1E102K B 15.3/74.3
C7 4030017460 S.CER ECJ0EB1E102K B 15.2/63.4
C8 4030017430 S.CER ECJ0EC1H101J B 22.7/83.3
C9 4030017430 S.CER ECJ0EC1H101J B 19.4/86.3
C10 4030017430 S.CER ECJ0EC1H101J B 19/87.8
C11 4030017460 S.CER ECJ0EB1E102K B 26.1/84.8
C12 4030017430 S.CER ECJ0EC1H101J B 24.2/84.1
C13 4030017430 S.CER ECJ0EC1H101J B 41.1/73.4
C15 4030017430 S.CER ECJ0EC1H101J B 17.5/87.8
C16 4030016790 S.CER ECJ0EB1C103K B 22.2/85.1
C17 4030009580 S.CER C1608 JB 1H 681K-T B 26.9/38.1
C18 4030009580 S.CER C1608 JB 1H 681K-T B 30.8/36.1
C19 4030009580 S.CER C1608 JB 1H 681K-T B 35.5/40.9
C101 4550006300 S.TAN ECST1AY475R B 13.8/80.6
C102 4030016930 S.CER ECJ0EB1A104K B 12.3/82.1
C103 4030016930 S.CER ECJ0EB1A104K B 16.4/32.6
C104 4030017420 S.CER ECJ0EC1H470J B 41.3/67.6
C105 4550006150 S.TAN ECST1CY105R B 7.2/90.4
C106 4550006620 S.TAN ECST0JY226R B 11.6/83.8
C107 4030016790 S.CER ECJ0EB1C103K B 10.8/85.4
C108 4030009580 S.CER C1608 JB 1H 681K-T B 15.4/43.3
C109 4030016930 S.CER ECJ0EB1A104K B 9/91.5
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[FRONT UNIT]
[L]=Low band, [H]=High band
