6 - 7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C607 4030017590 S.CER ECJ0EC1H070C [H] T 88.9/17.8
4030017630 S.CER ECJ0EC1H120J [L] T 88.9/17.8
C609 4030017610 S.CER ECJ0EC1H090C [H] T 91.5/30.4
C609 4030017630 S.CER ECJ0EC1H120J [L] T 91.5/30.4
C610 4030017590 S.CER ECJ0EC1H070C [H] T 93.9/22.8
4030017610 S.CER ECJ0EC1H090C [L] T 93.9/22.8
C612 4030017520 S.CER ECJ0EC1H0R3B T 91.7/18.3
C613 4030017350 S.CER ECJ0EC1H020B [H] T 91.7/31.6
4030017600 S.CER ECJ0EC1H080C [L] T 91.7/31.6
C614 4030017580 S.CER ECJ0EC1H060C [L] T 93.9/23.7
C615 4030017380 S.CER ECJ0EC1H050B [H] T 93.9/17.7
4030017590 S.CER ECJ0EC1H070C [L] T 93.9/17.7
C616 4030017390 S.CER ECJ0EC1H180J [L] T 95.8/31.1
4030017640 S.CER ECJ0EC1H150J [H] T 95.8/31.1
C617 4030017400 S.CER ECJ0EC1H220J [H] T 94.2/34.2
4030017650 S.CER ECJ0EC1H270J [L] T 94.2/34.2
C618 4030017390 S.CER ECJ0EC1H180J [L] T 96.3/24.7
4030017600 S.CER ECJ0EC1H080C [H] T 96.3/24.7
C619 4030017400 S.CER ECJ0EC1H220J [L] T 95.1/28.1
4030017640 S.CER ECJ0EC1H150J [H] T 95.1/28.1
C620 4030017620 S.CER ECJ0EC1H100C [H] T 96.3/18.4
4030017630 S.CER ECJ0EC1H120J [L] T 96.3/18.4
C621 4030017390 S.CER ECJ0EC1H180J T 95.5/22.2
C622 4030017540 S.CER ECJ0EC1HR75B T 97.9/31.9
C623 4030017730 S.CER ECJ0EB1E471K T 91.7/33.2
C624 4030017730 S.CER ECJ0EB1E471K T 93.3/19.5
C625 4030016790 S.CER ECJ0EB1C103K T 92.8/28.7
C626 4030017520 S.CER ECJ0EC1H0R3B [L] T 96.7/25.9
4030017540 S.CER ECJ0EC1HR75B [H] T 96.7/25.9
C627 4030017540 S.CER ECJ0EC1HR75B [L] T 96.7/23.1
4030017550 S.CER ECJ0EC1H1R5B [H] T 96.7/23.1
C628 4030016930 S.CER ECJ0EB1A104K B 93/25.5
C629 4030017430 S.CER ECJ0EC1H101J B 94.8/23.7
C630 4030017460 S.CER ECJ0EB1E102K B 92.6/18.7
C631 4030017730 S.CER ECJ0EB1E471K B 94.8/17.5
C632 4030017460 S.CER ECJ0EB1E102K B 96.6/29.4
C633 4030017460 S.CER ECJ0EB1E102K B 93.5/30.4
C634 4030017360 S.CER ECJ0EC1H030B [H] B 97.6/20.4
4030017560 S.CER ECJ0EC1H2R5B [L] B 97.6/20.4
C635 4030017350 S.CER ECJ0EC1H020B B 93/22.1
C636 4030017460 S.CER ECJ0EB1E102K B 95.7/17.5
C637 4030017460 S.CER ECJ0EB1E102K B 92.3/29.7
C638 4030017400 S.CER ECJ0EC1H220J B 88.8/31.3
C639 4030017460 S.CER ECJ0EB1E102K B 97.6/18.6
C640 4030017610 S.CER ECJ0EC1H090C [H] B 100.4/18
4030017630 S.CER ECJ0EC1H120J [L] B 100.4/18
C641 4030016930 S.CER ECJ0EB1A104K B 87.4/24.9
C645 4030017590 S.CER ECJ0EC1H070C B 90.5/31.3
C646 4030016790 S.CER ECJ0EB1C103K B 101.4/20.3
C647 4030017460 S.CER ECJ0EB1E102K B 76.1/4
C648 4030017460 S.CER ECJ0EB1E102K B 75.1/4
C649 4030017460 S.CER ECJ0EB1E102K T 9.6/25.4
C650 4030017460 S.CER ECJ0EB1E102K B 66.7/4
C651 4030017460 S.CER ECJ0EB1E102K B 64.8/5
C653 4030017460 S.CER ECJ0EB1E102K B 74/6.1
C654 4030017460 S.CER ECJ0EB1E102K B 74.1/4
C657 4030017460 S.CER ECJ0EB1E102K T 69.3/2.2
C658 4030017460 S.CER ECJ0EB1E102K B 68.5/4
C659 4030017460 S.CER ECJ0EB1E102K B 64.8/1.6
C660 4030017460 S.CER ECJ0EB1E102K T 67.1/2.2
C661 4030017360 S.CER ECJ0EC1H030B [L] B 98.3/16.2
4030017580 S.CER ECJ0EC1H060C [H] B 98.3/16.2
C662 4030017730 S.CER ECJ0EB1E471K B 74.8/8.1
C663 4030017730 S.CER ECJ0EB1E471K B 73.8/8.1
C665 4030017730 S.CER ECJ0EB1E471K B 73.1/11.7
C668 4030017730 S.CER ECJ0EB1E471K B 70.6/4.1
C669 4030017730 S.CER ECJ0EB1E471K B 72.1/11.7
C670 4030017730 S.CER ECJ0EB1E471K B 69.6/7.6
C671 4030017460 S.CER ECJ0EB1E102K B 77.1/4
J1 6510018430 S.CNR AXN330C038P T 16.1/7.5
J2 6510018430 S.CNR AXN330C038P T 38.2/6.3
J3 6510022710 S.CNR 30FLZ-SM1-TB T 70.5/6.6
F1 5210000830 S.FUS ERBFE3R00U T 120.1/31.8
S1 2260002800 S.SW SW-167 (SKQTLAE010) T 119.2/42.8
S2 2260002800 S.SW SW-167 (SKQTLAE010) T 109.8/42.8
S3 2260002840 SW SKHLLFA010
S4 2260002800 S.SW SW-167 (SKQTLAE010) T 66.4/42.8
EP1 6910015370 S.BEA ACZ1005Y-102-T B 65.2/41.2
EP300 6910015370 S.BEA ACZ1005Y-102-T B 43.6/24.5
EP301 6910015370 S.BEA ACZ1005Y-102-T B 34.5/33.2
EP600 6910015370 S.BEA ACZ1005Y-102-T T 92.8/27.8
EP601 6910015370 S.BEA ACZ1005Y-102-T B 25.3/21
EP602 6910015370 S.BEA ACZ1005Y-102-T B 25.3/20.1
IC1 1180002590 S.REG XC6204B332MR B 2.1/19.5
IC2 1180002740 S.REG R1230D151F-TR-F B 2.9/30.3
IC3 1180002590 S.REG XC6204B332MR T 23.7/7.5
IC4 1110003800 S.IC NJM2904V-TE1 T 14.5/11.8
IC5 1110006230 S.IC NJM2711F-TE1 B 14.6/16.4
IC7 1140011980 S.IC TMS320VC5416GGU120 B 11.8/30.4
IC8 1190002080 S.IC AD7476ARTZ-500RL7 T 14.7/18.4
IC9 1130011610 S.IC AK4550VT-E2 T 23.5/19.3
IC10 1110006230 S.IC NJM2711F-TE1 T 24.2/29.7
IC12 1140011880 S.IC HD64F2239TE16 T 11.8/30.4
IC13 1130003830 S.IC TC7S04F (TE85R) B 11.6/22.5
IC14 1110005730 S.IC S-80928CNMC-G8Y-T2 B 19.6/38.1
IC15 1130011600 S.IC TC7MET541AFK (EC) T 7/16.4
IC17 1130010390 S.IC HN58X2416TI B 8.9/38.5
Q1 1530002060 S.TR 2SC4081 T106 R B 23.4/22
FI1 2020001780 S.CER CFWCA450KEFA-R0 B 20.7/12.1
X1 6050012080 S.XTL CR-798 (12.288 MHz) T 23.4/36.3
L1 6200003590 S.COL EXCCL3225U1 T 23.5/2.5
L2 6200003960 S.COL MLF1608A 1R0K-T B 3.6/23.6
L3 6200003960 S.COL MLF1608A 1R0K-T T 24.6/12.1
L4 6200003960 S.COL MLF1608A 1R0K-T T 1/24.3
L5 6200003960 S.COL MLF1608A 1R0K-T B 3.6/24.8
L6 6200003960 S.COL MLF1608A 1R0K-T B 3.7/37.2
L7 6200011440 S.COL NLFV25T-330K-PF B 3.1/33.3
L8 6200003960 S.COL MLF1608A 1R0K-T B 21.1/5.4
R1 7030003860 S.RES ERJ3GE JPW V B 3.7/26
R2 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 16.3/6.4
R3 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 8.2/8
R4 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 19.6/8.4
R5 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 14/12.6
R6 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 11.5/16.8
R7 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 15.5/13.9
R8 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 20.5/8.4
R9 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 20.7/21.9
R10 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
) T 17.5/13.9
R12 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 4.3/9.8
R15 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 11.1/8.6
R16 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
) T 18.8/11.3
R17 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) B 21.6/21.2
R18 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 21.8/19.4
R19 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 13.7/13.9
R20 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 15.6/14.3
R21 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 11.2/13.9
R22 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 4.3/6.6
R23 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 5.5/8
R24 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 1.9/10.3
R25 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 7.3/8
R26 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 15.3/9.3
R27 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 2.7/7.6
R28 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 6.4/8
R29 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 4.6/6.2
R30 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 3.9/4.3
R31 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 3.6/2.8
R32 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 14.2/5.1
R33 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
) T 19.6/9.6
R34 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
) T 18.9/13.5
R35 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 19.6/19.5
R36 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 18.4/19.2
R37 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 18/17.7
R38 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 17.7/16
R39 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) T 17.7/15.1
R41 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 16.5/37.9
R42 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) T 12.1/16.1
R43 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 17.1/18.7
R44 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 20.7/14.1
R45 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) T 11.6/17.4
R46 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 16.1/22.6
R47 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 18.3/20
R48 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 23.8/14.9
R49 7030010040 S.RES ERJ2GE-JPW T 25/14.6
R50 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 20.9/31.5
R52 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 20.6/27.2
R53 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 18.5/30.5
R54 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 6.1/20.7
R55 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 2.7/34.4
R56 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 19.4/31
R57 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 23.4/19.5
R58 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 24.7/20.2
R59 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 25.7/37.3
R61 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 25.1/22.3
R62 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 25.4/32.2
R63 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 25.7/33.8
[L]=Low band, [H]=High band
[DSP UNIT] (IC-F80DT/DS only)
To Next Page
