Icom IC-F8101 Service Manual

5-7
ADJUSTMENT
TRANSCEIVER’S
CONDITION
OPERATION
ADJUSTMENT
ITEM
VALUE
REFERENCE
FREQUENCY
NOTE: Start this adjustment after the transceiver is cooled.
1 • Channel: 6
• Mode: CW
• Transmitting
• Test equipment
Connect the test equipment
to the antenna connector.
Simple 25/30
(Factory Menu)
"REF Freq."
29.000000 MHz
(±2 Hz)
IDLING 1 • Channel: 7
• Mode: USB
• Receiving
• Connect an ammeter to the
DC power cable.
Simple 2/30
(Factory Menu)
"ID3V 6"
"0"
2 Simple 7/30 to
Simple 20/30
(Factory Menu)
"ID4V 1"
to
“ID4V 8”
"0"
3 • Transmitting
(Apply no audio
to [MIC].)
––
Note the current
value as the refer-
ence.
4
Simple 2/30
(Factory Menu)
"ID3V 6"
1.5 A more than
the value shown in
"Step 3."
5 Simple 1/30,
Simple 3/30 to
Simple 6/30
(Factory Menu)
"ID3V 1– 5"
"ID3V 7"
"ID3V 8"
The same driving
current as "ID3V 6"
adjustment.
6 • Channel: 8
• Transmitting
Simple 7/30
(Factory Menu)
"ID4V 1"
0.8 A more than
the value shown in
"Step 4."
7 • Channel: 9
• Transmitting
Simple 8/30
(Factory Menu)
"ID4V 2"
0.7 A more than
the value shown in
"Step 4."
8 • Channel: 10
• Transmitting
Simple 9/30
(Factory Menu)
"ID4V 3"
0.7 A more than
the value shown in
"Step 4."
9 • Channel: 11
• Transmitting
Simple 10/30
(Factory Menu)
"ID4V 4 1"
0.3 A more than
the value shown in
"Step 4."
10 • Channel: 12
• Transmitting
Simple 11/30
(Factory Menu)
"ID4V 4 2"
0.3 A more than
the value shown in
"Step 4."
11 • Channel: 13
• Transmitting
Simple 12/30
(Factory Menu)
"ID4V 5"
0.3 A more than
the value shown in
"Step 4."
12 • Channel: 14
• Transmitting
Simple 14/30
(Factory Menu)
"ID4V 6 2"
0.3 A more than
the value shown in
"Step 4."
13 • Channel: 15
• Transmitting
Simple 13/30,
(Factory Menu)
"ID4V 6 1"
The same value as
in "Step 12."
14 • Channel: 16
• Transmitting
Simple 15/30
(F
actory Menu)
"ID4V 7 1"
The same value as
in "Step 12."
15 • Channel: 17
• Transmitting
Simple 16/30
(Factory Menu)
"ID4V 7 2"
0.2 A more than
the value shown in
"Step 4."
16 • Channel: 18
• Transmitting
Simple 17/30
(Factory Menu)
"ID4V 7 3"
0.2 A more than
the value shown in
"Step 4."
17 • Channel: 19
• Transmitting
Simple 18/30
(Factory Menu)
"ID4V 8 1"
0.2 A more than
the value shown in
"Step 4."
18 • Channel: 20
• Transmitting
Simple 19/30
(Factory Menu)
"ID4V 8 2"
0.2 A more than
the value shown in
"Step 4."
19 • Channel: 21
• Transmitting
Simple 20/30
(Factory Menu)
"ID4V 8 3"
0.2 A more than
the value shown in
"Step 4."
5-3 TRANSMIT ADJUSTMENTS
