Measurement method
Frequency range
Type of emission
Channel spacing
Frequency stability
Number of channels
Antenna connector
Power supply requirement
Current drain (approx.)
Operating temperature range
Dimensions (proj. not included)
Weight
RF output power (High/Low)
Modulation system
Maximum frequency deviation
Spurious emissions
Adjacent channel power
Input impedance
Receive system
Intermediate frequencies
Sensitivity (typical)
Adjacent channel selectivity (typical)
Spurious response
Intermodulation (typical)
Audio output power
Audio output impedance
[USA2], [GEN2], [GEN4] [EUR2], [FRG2]
SECTION 1 SPECIFICATIONS
1- 1
All stated specifications are subject to change without notice or obligation.
RECEIVER TRANSMITTER GENERAL
EIA / TIA-603 ETS 300 086
150.000–174.000 MHz
W/N (25 kHz; Wide / 12.5 kHz; Narrow): 16K0F3E / 8K50F3E
[USA2], [GEN2], [GEN4], [EUR2]
M/N (20 kHz; Middle / 12.5 kHz; Narrow): 14K0F3E / 8K50F3E [FRG2]
25 or 12.5 kHz (Wide / Narrow)
20 or 12.5 kHz (Middle / Narrow)
±2.5 ppm ±1.0 kHz
Max. 32 channel
N-type
× 2 (50 Ω)
100 V–120 V [USA2], [GEN2]
220 V–240 V [GEN4], [EUR2], [FRG2]
13.6 V DC (negative ground) 13.2 V DC (negative ground)
TX (at 50 W) 15.0 A TX (at 25 W) 10.0 A
RX (max. audio) 2 A
(stand-by) 1 A
–30˚C to +60˚C (–22˚F to +140˚F) –25˚C to +55˚C
410(W) × 110(H) × 360(D) mm; 16.1 (W)
×4.3 (H) × 14.1 (D) inch
12 kg; 26.5 lb
50 W / 10 W 25 W / 5 W
Variable reactance frequency modulation
±5.0 kHz [Wide], ±4.0 kHz [Middle], ±2.5 kHz [Narrow]
70 dBc typical 0.25 µW ≤ 1GHz, 1.0 µW > 1 GHz
70 dB [Wide]/[middle], 60 dB [Narrow]
600 Ω
Double-conversion superheterodyne system
1st: 31.65 MHz, 2nd: 455 kHz
0.5 µV at 12 dB SINAD 6 dBµV (emf) at 20 dB SINAD
70 dB [Wide]/[Middle], 60 dB [Narrow]
70 dB
70 dB
2.5 W typical at 10% distortion with a 4 Ω load
4 Ω
