Icom IC-FR3000 Service Manual

Q1 1530002060 S.TRANSISTOR 2SC4081 T106 R
D1 1750000930 S.DIODE NNCD8.2C-T1
D2 1750000930 S.DIODE NNCD8.2C-T1
D3 1750000930 S.DIODE NNCD8.2C-T1
L1 6200001620 S.COIL ELJFC 1R0K-F
R1 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R2 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R3 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R8 7030001150 S.RESISTOR MCR50JZHJ 150 Ω (151)
R9 7030001150 S.RESISTOR MCR50JZHJ 150 Ω (151)
R10 7030001160 S.RESISTOR MCR50JZHJ 180 Ω (181)
R11 7030001150 S.RESISTOR MCR50JZHJ 150 Ω (151)
R12 7030001150 S.RESISTOR MCR50JZHJ 150 Ω (151)
R13 7030001150 S.RESISTOR MCR50JZHJ 150 Ω (151)
R15 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R17 7030008220 S.RESISTOR MCR100JZHJ 47 Ω (470)
R18 7030008220 S.RESISTOR MCR100JZHJ 47 Ω (470)
R19 7540000240 S.ABSORBER KU10R29N-4063
R21 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R22 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R23 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R24 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R26 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R27 7030010910 S.RESISTOR ERJ1TYJ 150U (15 Ω)
R28 7030010910 S.RESISTOR ERJ1TYJ 150U (15 Ω)
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C3 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C4 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C14 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C16 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C17 4030017200 S.CERAMIC GRM31BR32J102KY01L
C18 4030017200 S.CERAMIC GRM31BR32J102KY01L
J1 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT
J2 6510022580 S.CONNECTOR 24FMN-BMTTR-A-TBT
J3 6510021600 S.CONNECTOR S2B-PH-SM3-TB
J4 6510022910 CONNECTOR IMSA9201B-1-16Z012Z
J6 6510022790 CONNECTOR 95003-2641
J7 6450001470 CONNECTOR 95003-2881
J8 6510023250 S.CONNECTOR S3B-PH-SM3-TB
J9 6510021600 S.CONNECTOR S2B-PH-SM3-TB
DS1 5040001820 LED BG3889S
DS2 5040001820 LED BG3889S
DS3 5040001330 LED BR3889S
DS4 5040001820 LED BG3889S
DS5 5040001820 LED BG3889S
DS6 5040001820 LED BG3889S
DS7 5030002190 LCD MSC-C161UYLT-4W
S1 2260001680 S.SWITCH SKQDPB
S2 2260001680 S.SWITCH SKQDPB
S3 2260001680 S.SWITCH SKQDPB
S4 2260001680 S.SWITCH SKQDPB
S5 2260001680 S.SWITCH SKQDPB
S6 2260001680 S.SWITCH SKQDPB
S7 2260001680 S.SWITCH SKQDPB
S8 2260001680 S.SWITCH SKQDPB
EP1 0910056085 PCB B 5652E
EP2 6910014560 SPACER LM-15
EP3 6910014550 SPACER LM-13
EP4 6910014540 SPACER LM-10
EP5 6910014540 SPACER LM-10
EP6 6910014540 SPACER LM-10
S.=Surface mount
[FRONT UNIT][FRONT UNIT]
EP7 6910014540 SPACER LM-10
IC1 1110003780 S.IC NJM2902V-TE1
IC2 1110003780 S.IC NJM2902V-TE1
IC3 1110003780 S.IC NJM2902V-TE1
IC4 1110003780 S.IC NJM2902V-TE1
IC6 1110002400 S.IC NJM2107F-TE1
IC7 1110003780 S.IC NJM2902V-TE1
IC8 1110003780 S.IC NJM2902V-TE1
IC9 1110003780 S.IC NJM2902V-TE1
IC10 1110003780 S.IC NJM2902V-TE1
IC11 1180000420 S.IC TA78L05F (TE12R)
IC12 1110003780 S.IC NJM2902V-TE1
IC13 1130008090 S.IC BU4066BCFV-E1
IC14 1130004200 S.IC TC4S66F (TE85R)
IC16 1130006220 S.IC TC4W53FU (TE12L)
IC17 1110003090 IC LA4425A
IC20 1130006220 S.IC TC4W53FU (TE12L)
IC21 1130006220 S.IC TC4W53FU (TE12L)
IC25 1190001350 S.IC M62364FP 600D
IC26 1110003800 S.IC NJM2904V-TE1
IC28 1110002400 S.IC NJM2107F-TE1
IC29 1190001720 S.IC FX805LG
IC30 1130006220 S.IC TC4W53FU (TE12L)
IC31 1130007400 S.IC LC7387M-TRM
IC32 1130006220 S.IC TC4W53FU (TE12L)
IC33 1140010140 S.IC HD64F2238BFA13
IC34 1110005710 S.IC S-80842CLUA-B63-T2
IC35 1130009320 S.IC BU4011BFV-E2
IC36 1130009320 S.IC BU4011BFV-E2
IC37 1140008650 S.IC HN58X2464TI
IC38 1180002250 S.IC S-812C50AMC-C3E-T2
IC39 1130007570 S.IC BU4094BCFV-E2
IC40 1130007570 S.IC BU4094BCFV-E2
IC41 1130007570 S.IC BU4094BCFV-E2
IC42 1170000280 S.IC TLP121 (GB-TPL)
IC43 1170000280 S.IC TLP121 (GB-TPL)
IC44 1120002830 S.IC NJM2125F-TE1
IC45 1110005000 S.IC LMC567CM
IC46 1190001740 S.IC BA6566F-E2
IC47 1190001730 S.IC LC73701M-TLM
IC48 1170000280 S.IC TLP121 (GB-TPL)
IC49 1170000280 S.IC TLP121 (GB-TPL)
IC50 1130006220 S.IC TC4W53FU (TE12L)
IC51 1110002400 S.IC NJM2107F-TE1
IC52 1110005690 S.IC NJM2520V-TE1
IC53 1130006220 S.IC TC4W53FU (TE12L)
Q1 1590001400 S.TRANSISTOR XP1214 (TX)
Q2 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q3 1590001940 S.TRANSISTOR DTC144EE TL
Q4 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q5 1510000510 S.TRANSISTOR 2SA1576A T106R
Q6 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q7 1590001400 S.TRANSISTOR XP1214 (TX)
Q8 1590003210 S.TRANSISTOR XP1111 (TX)
Q9 1590003210 S.TRANSISTOR XP1111 (TX)
Q10 1590003210 S.TRANSISTOR XP1111 (TX)
Q11 1590003210 S.TRANSISTOR XP1111 (TX)
Q17 1590001940 S.TRANSISTOR DTC144EE TL
Q18 1590002010 S.TRANSISTOR XP1114 (TX)
Q19 1590002010 S.TRANSISTOR XP1114 (TX)
Q20 1590002010 S.TRANSISTOR XP1114 (TX)
Q24 1550000020 S.FET 2SJ377 (TE16R)
Q25 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q26 1590001960 S.TRANSISTOR XP4311 (TX)
Q27 1590001960 S.TRANSISTOR XP4311 (TX)
Q28 1590001960 S.TRANSISTOR XP4311 (TX)
Q29 1590001960 S.TRANSISTOR XP4311 (TX)
Q37 1590001940 S.TRANSISTOR DTC144EE TL
Q38 1590001400 S.TRANSISTOR XP1214 (TX)
Q40 1590001940 S.TRANSISTOR DTC144EE TL
5 - 2
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
