Icom IC-FR3000 Service Manual

[REG UNIT][REG UNIT]
IC1 1180001320 IC NJM7809FA
IC2 1180002290 S.IC NJM7809DL1A-TE
IC3 1180001860 S.IC TA78M05F (TE16L)
IC4 1180002480 S.REG TA78DL12AF (TE16L)
IC6 1180001540 S.IC TA78L08F (TE12R)
IC7 1110002860 S.IC TA75S393F (TE85R)
IC8 1110002860 S.IC TA75S393F (TE85R)
IC9 1110002400 S.IC NJM2107F-TE1
IC11 1110002750 S.IC TA75S01F (TE85R)
Q1 1590003110 FET 2SJ533
Q4 1590003110 FET 2SJ533
Q5 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q7 1590001940 S.TRANSISTOR DTC144EE TL
Q8 1590003030 S.FET 2SJ553STR
Q9 1590001940 S.TRANSISTOR DTC144EE TL
D2 1750000550 S.DIODE 1SS355 TE-17
D3 1790000700 DIODE DSA3A1
D4 1710001170 DIODE FCH30A03L
D6 1790000720 DIODE MA29W-B
D7 1710001170 DIODE FCH30A03L
D8 1730002340 S.ZENER MA8047-M (TX)
R3 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R14 7100000830 RESISTOR 5SG 3.3 Ω
R16 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R17 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R18 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R19 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R21 7030010410 S.RESISTOR ERJ1TYJ 220U (22 Ω)
R23 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R24 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R24 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R27 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R30 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R31 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R32 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R33 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R34 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R35 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R36 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R37 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R38 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R39 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R40 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R41 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R42 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R58 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R59 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R60 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R61 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R62 7030010510 S.RESISTOR ERJ1TYJ 8R2U (8.2 Ω)
R64 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R65 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R66 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R67 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R68 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
C4 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C6 4510007690 ELECTROLYTIC LXZ25VB2200
C7 4510007690 ELECTROLYTIC LXZ25VB2200
C9 4510007690 ELECTROLYTIC LXZ25VB2200
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C20 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C24 4550006770 S.TANTALUM TEMSVD2 1C 476M-12R
S.=Surface mount
C25 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C26 4510007660 ELECTROLYTIC LXZ25VB100
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C28 4510007650 S.ELECTROLYTIC EEVHB1C470P
C29 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C31 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C33 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C34 4510007570
S.ELECTROLYTIC EEVHB1C220UR
C35 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C36 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C37 4510007660 ELECTROLYTIC LXZ25VB100
C38 4510007660 ELECTROLYTIC LXZ25VB100
C41 4510007570
S.ELECTROLYTIC EEVHB1C220UR
C42 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C43 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C45 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C47 4510007660 ELECTROLYTIC LXZ25VB100
C48 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C49 4510007570 S.ELECTROLYTIC EEVHB1C220UR
C50 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C51 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C52 4030017490 S.CERAMIC C1608 JB 1A 105K-T
RL2 6330001680 RELAY ACB32101
J13 6510018970 S.CONNECTOR B4B-PH-SM3-TB
J14 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT
J16 6510018960 S.CONNECTOR B2B-PH-SM3-TB
J17 6510018960 S.CONNECTOR B2B-PH-SM3-TB
J18 6510018960 S.CONNECTOR B2B-PH-SM3-TB
F1 5220000300 HOLDER 1A5600
F2 5220000300 HOLDER 1A5600
F3 5210000850 FUSE ATC-20
F4 5220000300 HOLDER 1A5600
F5 5220000300 HOLDER 1A5600
F6 5210000850 FUSE ATC-20
W1 7120000490 JUMPER ERD25T0
W2 7120000490 JUMPER ERD25T0
W3 7120000490 JUMPER ERD25T0
W4 7120000490 JUMPER ERD25T0
EP1 0910056075 PCB B 5651E
EP2 6910012350 S.BEAD MMZ1608Y 102BT
EP3 6910011340 TERMINAL OT-010 M3
EP4 6910011340 TERMINAL OT-010 M3
EP5 6910011340 TERMINAL OT-010 M3
EP6 6910011340 TERMINAL OT-010 M3
EP7 6910011340 TERMINAL OT-010 M3
EP8 6910011340 TERMINAL OT-010 M3
EP9 6910011340 TERMINAL OT-010 M3
EP10 6910011340 TERMINAL OT-010 M3
5 - 1
SECTION 5 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
