4 - 2
■ BEFORE ENTERING THE ADJUSTMENT MODE
CAUTION!: Need to back up the original memory data using CS-FR3000 before cloning the adjustment frequencies.
When program the adjustment frequencies into the repeater, the repeater’s memory channels will be overwritten
the data and deleted original memory data at the same time.
Need to do cloning “Adjustment Mode Access” permitting and adjustment frequencies into the CPU using with the CS-FR3000
before entering the adjustment mode. Otherwise, the repeater can not enter the adjustment mode.
■ PROCESS TO PERMIT “ADJUSTMENT MODE ACCESS”
1 Run the CS-FR3000 CLONING SOFTWARE.
2 Open the “Common Setting” folder .
3 Click the “Expert” card on the tree view window.
4 Double-click somewhere on the Common setting screen window, then appear the “Edit Expert” window.
5 Click the “Expert 2” tab, then click the “Adjustment Mode Access” check box.
6 Click “OK” button.
7 Click the “Memory CH” card on the tree view window.
8 Input all adjustment frequencies as page 4-4.
9 Cloning to the repeater then the repeater can be enter the adjustment mode.
Show the next page to enter the adjustment mode.
To Next Page
