SPECIFICATIONS
9
30
General
• Frequency coverage : Transmit 156–157.5 MHz
Receive 156–163 MHz
• Usable channels : All U.S.A., International and
Canadian channels plus 10
weather channels
• Mode : 16K0G3E, (16K0G2B
when
optional DSC is in use
)
• Power supply requirement : 13.8 V DC ± 15%
• Current drain : Transmit
(at 13.8 V DC) high power 6.0 A
low power 1.5 A
Receive
standby 350 mA
max. audio output 1.2 A
• Frequency stability : ± 10 ppm
• Usable temp. range : –20°C to +60°C;
–4°F to +140°F
• Dimensions : 140(W) x 55(H) x 155(D) mm
(projections not included) 5
1
⁄2(W) x 2
5
⁄32(H) x 6
3
⁄32(D) in
• Weight : 1.0 kg; 2.2 lb
Transmitter
• Output power : High 25 W Low 1 W
• Modulation system : Variable reactance phase
modulation
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –70 dB
• Microphone impedance : 600 Ω
Receiver
• Receive system : Double conversion
superheterodyne
• Intermediate frequencies : 1st 21.8 MHz 2nd 455 kHz
• Sensitivity : 0.22 µV (typical)
for 12 dB SINAD
• Squelch sensitivity : 0.18 µV at threshold
• Adjacent channel : More than 70 dB
selectivity
• Spurious reponse : More than 70 dB
rejection
• Intermodulation rejection : More than 70 dB
• Audio output power : 3.5 W
at 10% distortion
• Audio output impedance : 4 Ω
All stated specifications are subject to change without notice or
obligation
