Icom IC-R75 Service Manual

S.=Surface mount
R131 7210003040 VARIABLE TP96D26-22F-10KBX2-2240
R141 7210003030 VARIABLE TP96D00-22F-10KBX2-2240
R143 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
J101 6510020710 S.CONNECTOR 52793-1090
EP1 0910051172 PCB B 5271B
L121 6200003950 S.COIL HF50ACC 322513-T
R121 7030006070 S.RESISTOR ERJ12YJ101H (100 Ω)
R122 7030006070 S.RESISTOR ERJ12YJ101H (100 Ω)
C121 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C122 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C123 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
J101 6510020710 S.CONNECTOR 52793-1090
J121 6510021480 CONNECTOR HLJ2307-01-3070
EP1 0910051182 PCB B 5272B
IC101 1140008250 S.IC HD6433837SC58H
IC231 1140005880 S.IC X25320S8I-2.7T6
IC351 1110003690 S.IC M62354GP 75EC
IC391 1130009110 S.IC S-80942ANMP-DD6-T2
IC392 1130006440 S.IC TC7S08F (TE85R)
IC401 1130004921 S.IC TC74HC04AF (TP1)
Q351 1590000680 S.TRANSISTOR DTC114EUA T106
Q391 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q401 1590001650 S.TRANSISTOR XP4601 (TX)
Q421 1590000720 S.TRANSISTOR DTA144EUA T106
Q511 1510000510 S.TRANSISTOR 2SA1576A T106R
Q512 1590001650 S.TRANSISTOR XP4601 (TX)
D381 1730002320 S.ZENER MA8051-M (TX)
D382 1790000970 S.DIODE MA729 (TX)
D393 1750000550 S.DIODE 1SS355 TE-17
D401 1750000550 S.DIODE 1SS355 TE-17
D461 1730002530 S.ZENER NNCD6.2G-T1
X111 6050009460 S.XTAL CM200S SMD (32.768KHZ)
X112 6050009870 S.XTAL CR-567 (9.8304 MHz)
L491 6200003950 S.COIL HF50ACC 322513-T
L492 6200003950 S.COIL HF50ACC 322513-T
L501 6200002970 S.COIL NL 322522T-121J
L502 6200002970 S.COIL NL 322522T-121J
L503 6200003950 S.COIL HF50ACC 322513-T
R112 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R121 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R122 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R123 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R124 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R125 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R126 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R127 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R128 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R129 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R130 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R131 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R141 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R142 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R143 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R144 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R145 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R146 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R147 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R148 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R149 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R150 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R151 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R152 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R153 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R154 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R155 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R161 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R162 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R163 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R171 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R172 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R173 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R174 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R175 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R176 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R177 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R178 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R179 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R191 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R192 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R193 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R194 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R195 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R196 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R197 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R198 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R201 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R202 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R203 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R204 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R205 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R206 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R208 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R209 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R210 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R211 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R221 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R223 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R224 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R225 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R231 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R251 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R252 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R253 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R254 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R255 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R256 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R257 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R258 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R259 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R260 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R261 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
5 - 1
SECTION 5 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
[VR BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[PHONE BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC BOARD]
