8 - 1
8-1 PHONE AND VR BOARDS
SECTION 8 BOARD LAYOUTS
R122
R121
C123 C122
C121
L121
• VR BOARD
R131 R141
J101
J101
to LOGIC board J451
R143
GND
GND
GND
GND
GND
PB2L
PB1L
RFGL
AFGL
5VL
110
• PHONE BOARD
TOP VIEW
