2 - 1
SECTION 2 INSIDE VIEWS
2nd IF filter
(FI761: FL-272)
3rd LO circuit
3rd mixer circuit
(IC811)
BFO circuit
2nd IF circuit
PLL IC (IC21)
Noise blaker circuit
VCO circuit
BFO mixer circuit
(IC1101)
Bandpass filter
Fuse (3A)
MAIN UNIT PLL UNIT
Back up battery
(BT 1521)
3rd IF filter
(FI851)
2nd mixer circuit
1st IF filter (FI701)
1st mixer circuit
