5 - 12
5-3 TRANSMIT ADJUSTMENT (Continued)
5-4 RECEIVE ADJUSTMENTS (Continued)
1) Select an adjustment item (band) using
/
.
2) Set the SSG as specifi ed (frequency, deviation and output level), and then push
to automatically adjust.
ADJUSTMENT
ADJUSTMENT
ITEM
OPERATION VALUE
S-METER
[A-BAND]
NOTE:
“RECEIVE SENSITIVITY” must be adjusted before “S-METER” and “S-METER S3 LEVEL.” Other-
wise, “S-METER” and “S-METER S3 LEVEL will not be adjusted properly.
–
1 1) Set the power supply voltage to 7.4 V.
2) Connect an SSG to the antenna connector and set it as;
Modulation : 1 kHz
Deviation : 3.5 kHz
–
(VHF S0 level)
[VS0]
2 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –10 dBµ (–117 dBm)
†
Push .
(Automatic
adjustment)
(VHF S3 level)
[VS3]
3 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –6 dBµ (–113 dBm)
†
(VHF Full scale)
[VSF]
4 • Set the SSG as;
Level : +10 dBµ (–97 dBm)
†
(UHF S0 level)
[US0]
5 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –10 dBµ (–117 dBm)
†
(UHF S3 level)
[US3]
6 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –6 dBµ (–113 dBm)
†
(UHF Full scale)
[USF]
7 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : +10 dBµ (–97 dBm)
†
S-METER
[AIR BAND]
NOTE:
“RECEIVE SENSITIVITY” must be adjusted before “S-METER” and “S-METER S3 LEVEL.” Other-
wise, “S-METER” and “S-METER S3 LEVEL will not be adjusted properly.
–
1 1) Set the power supply voltage to 7.4 V.
2) Connect an SSG to the antenna connector and set it as;
Modulation : 1 kHz
Deviation : 30% (AM)
–
(AIR S0 level)
[AS0]
2 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –10 dBµ (–117 dBm)
†
Push .
(Automatic
adjustment)
(AIR S3 level)
[AS3]
3 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –6 dBµ (–113 dBm)
†
(AIR Full scale)
[ASF]
4 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : +10 dBµ (–97 dBm)
†
S-METER
[B BAND]
–
1 1) Set the power supply voltage to 7.4 V.
2) Connect an SSG to the antenna connector, and then set it as;
Frequency : (Displayed on the function display)
Modulation : 1 kHz
Deviation : 3.5 kHz
–
(VHF S0 level)
[VS0]
2 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –10 dBµ (–117 dBm)
†
Push .
(Automatic
adjustment)
(VHF S3 level)
[VS3]
3 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –6 dBµ (–113 dBm)
†
(VHF Full scale)
[VSF]
4 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : +10 dBµ (–97 dBm)
†
(UHF S0 level)
[US0]
5 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –10 dBµ (–117 dBm)
†
(UHF S3 level)
[US3]
6 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –6 dBµ (–113 dBm)
†
(UHF Full scale)
[USF]
7 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : +10 dBµ (–97 dBm)
†
†
; This output level of a standard signal generator (SSG) is indicated as SSG’s open circuit.
