IDEAL imax plus F80 User Manual

29
- Installation & Servicing
INSTALLATION
32 TEST MODE
By pressing the mode key three times, TEST mode is displayed. In this mode it is possible to run either the entire boiler or
individual burners at max. or min. rate. This mode is useful for measuring the combustion and gas rates.
Press Display Press Display Press Description
Test mode off for all burner modules
Test mode high for all burner modules
Test mode low for all burner modules
Test mode off for burner module 1
Test mode high for burner module 1
Test mode low for burner module 1
Test mode off for burner module 2
Test mode high for burner module 2
Test mode low for burner module 2
Test mode off for burner module 3
Test mode high for burner module 3
Test mode low for burner module 3
Test mode off for burner module 4
Test mode high for burner module 4
Test mode low for burner module 4
STEP
A L L
STEP
B U R. 1
STEP
B U R. 2
STEP
B U R. 3
STEP
B U R. 4
STORE
STORE
STORE
STORE
+
-
+
-
+
-
+
-
+
-
STORE
O F F
=
H H H
=
L L L
=
O F F
=
H I
=
L O
=
O F F
=
H I
=
L O
=
O F F
=
H I
=
L O
=
O F F
=
H I
=
L O
=
Test mode off for burner module 5
Test mode high for burner module 5
Test mode low for burner module 5
STEP
B U R. 5
STORE
+
-
O F F
=
H I
=
L O
=
Test mode off for burner module 6
Test mode high for burner module 6
Test mode low for burner module 6
STEP
B U R. 6
STORE
+
-
O F F
=
H I
=
L O
=
Test mode off for burner module 7
Test mode high for burner module 7
Test mode low for burner module 7
STEP
B U R. 7
STORE
+
-
O F F
=
H I
=
L O
=
T E S T
Press Display
MODE
Three times
A L L
Press Display
STEP
O F F
+=
FLASHING
ALTERNATELY
INSTALLATION
