 START-UP KIT
Each start-up kit contains one (1) bottle of Ingersoll-Rand
Contractor Series Synthetic Lubricant, one (1) air lter
element and the necessary engine parts and oil to start-up
and maintain your unit for the rst year.
PART NO DESCRIPTION
47623376001 START-UP KIT (KOHLER) 5.5HP
97339501 START-UP KIT (HONDA) 5.5HP
47633855001 START-UP KIT (KOHLER) 9.5 HP
 INGERSOLL-RAND SYNTHETIC COMPRESSOR
LUBRICANT
PART NO DESCRIPTION
97338131 LUBRICANT, 5L, BOTTLE
97338149 LUBRICANT, 6-PACK OF 5L
BOTTLES
 AIR FILTER ELEMENT
PART NO DESCRIPTION
70243712 AIR FILTER ELEMENT SS3
32170979 AIR FILTER ELEMENT SS5
 STEP SAVER KITS
Step Saver Kits provide all of the parts required to perform
common repair tasks such as piston ring replacement or valve
replacement.
PART NO DESCRIPTION CONTENTS
97338107 KIT, VALVE/GASKET
SS3
Valve wearing parts and
head gaskets that are
destroyed in replacing
valve parts.
97338115 KIT, RING/GASKET
SS3
Complete set of piston
rings, a crankshaft seal,
and gaskets that are
destroyed in breaking
the unit down to
replace the rings
20100277 KIT, VALVE/GASKET
SS5
Valve wearing parts and
head gaskets that are
destroyed in replacing
valve parts.
20100285 KIT, RING/GASKET
SS5
Complete set of piston
rings, a crankshaft seal,
and gaskets that are
destroyed in breaking
the unit down to
replace the rings
 CRANKCASE HEATER KIT
Crankcase heaters are recommended when ambient
temperatures are consistently below 32° F (0°C). An easy-
to-install external crankcase heater kit is intended for
aftermarket use.
PART NO DESCRIPTION
97330385 KIT, CRANKCASE HEATER
 MULTI-PURPOSE AIR HOSES
These air hose asemblies are heavy duty, light weight hoses
designed for 300 PSIG working pressure.
PART NO DESCRIPTION
32323750 HOSE, AIR 3/8” x 25’ (1/4”
MALE NPT)
32323768 HOSE, AIR 3/8” x 50’ (1/4”
MALE NPT)
32323776 HOSE, AIR 3/8” x 100’ (1/4”
MALE NPT)
 ENGINE PARTS
PART NO DESCRIPTION
32498552 OIL, ENGINE - QUART
47629343001 COMPLETE, FILTER 5.5HP
(KOHLER)
54405071 ELEMENT, ENGINE AIR FILTER
(HONDA) 5.5HP
47634393001 FILTER 9.5HP
KITS & ACCESSORIES
RELEASED 13/Feb/2019 14:38:46 GMT

Ingersoll-Rand SS3 Specifications

General

Horsepower	3 HP
Tank Capacity	60 gallons
Max Pressure	135 PSI
Voltage	230V
Pump Type	Single-stage
Power Source	Electric
CFM @ 90 PSI	11.3 CFM
Tank Size	60 gallons
Phase	Single-phase
