Inovance MD200 User Manual

1 Product Information
- 5 -
1.2 General Specications
Voltage class 200 VAC to 240 VAC
Model: MD200SxxB(1) 0.4 0.75 1.5 2.2
Dimension(2) Height, Width, Depth [H]: 160 mm, [H1]: 180 mm, [W]: 75 mm, [D]: 145 mm
Mounting Hole, [mm] Φ5.0
Drive Input
Rated Input voltage 1 PH, 200 VAC to 240 VAC , -15% to +10%
Rated input current, [A] 6.5 11.0 18.0 27.0
Rated input frequency 50/60 Hz, ±5%
Power capacity, [kVA] 1.7 3.0 4.8 7.1
Drive Output
Applicable motor
[kW] 0.4 0.75 1.5 2.2
[HP] 0.5 1 2 3
Output current, [A] 2.6 4.6 8.0 11.0
Default carrier frequency, [kHz] 6 6 6 6
Overload capacity 150% for 60 s
Max. output voltage 3 PH, 0 to 240 VAC
Max. output frequency 50 to 500 Hz
Braking Resistor
Recommended power, [W] 80 80 100 100
Recommended resistance, min. [Ω] 200 150 100 70
Weight, [kg] 1.1
Voltage class 380 VAC to 480 VAC
Model: MD200TxxB(1) 0.4 0.75 1.5 2.2 3.7
Dimension(2) Height, Width, Depth [H]: 160 mm, [H1]: 180 mm, [W] : 75 mm, [D] : 145 mm
Mounting Hole [mm] Φ5.0
Drive Input
Rated Input Voltage 3 PH 380 to 480 VAC, -15% to +10%
Rated Input Current, [A] 2.6 4.5 5.5 6.5 11.0
Rated input frequency 50/60 Hz, ±5%
Power Capacity, [kVA] 1.0 1.5 3.0 4.0 5.9
Drive Output
Applicable Motor
[kW] 0.4 0.75 1.5 2.2 3.7
[HP] 0.5 1 2 3 5
Output Current, [A] 1.8 3.4 4.8 5.5 9.5
Default carrier
Frequency, [kHz]
6 6 6 6 4
Overload Capacity 150% for 60 s
Max. output voltage 3 PH, 0 to 480 VAC
Max. output frequency 50 to 500 Hz
Braking Resistor
Recommended
Power, [W]
150 150 250 300 400
Recommended
Resistance, min. [Ω]
300 300 220 200 130
Mass, [kg] 1.1

Inovance MD200 Specifications

General

Frequency Range	0-400 Hz
Storage Temperature	-20°C to +60°C
Control Mode	V/F control
Speed Range	1:100
Protection	Overcurrent, overvoltage, undervoltage, overload, short circuit
Communication Interface	RS485
Operating Temperature	-10°C to +40°C (derating above 40°C)
Humidity	5% to 95% RH, non-condensing
Altitude	Up to 1000m (derating above 1000m)
