Inovance Monarch NICE300new Series User Manual

- 72 -
3 System Functions
3
Related Parameters
The parameter setting related to emergency evacuation by controller drive is described in the following
table.
Parameter No. Parameter Name Value Remarks
F8-10
Emergency evacuation
operation mode at
power failure
1: UPS -
F5-20 (X20) X20 function selection 59 (UPS valid signal)
Assume that X20 is used as the NC input
of emergency evacuation signal
F5-31 (Y6) Y6 function selection
13 (Emergency evacuation
automatic switchover)
Only Y6 can be used for emergency
evacuation output.
The parameter setting related to emergency evacuation by shorting stator braking is described in the
following table.
Parameter
No.
Parameter Name Value Remarks
F8-10
Emergency evacuation
operation mode at
power failure
0: Motor not running -
F5-20 (X20) X20 function selection 59 (UPS valid signal)
Assume that X20 is used as the NC input
of emergency evacuation signal
F5-31 (Y6) Y6 function selection
13 (Emergency evacuation
automatic switchover)
Only Y6 can be used for emergency
evacuation output.
F6-45
Bit15 (Shorting stator
braking function)
1 (Enabled)
Enable the function of shorting stator
braking.
The UPS power is recommended in the following table.
Table 3-3 Recommended UPS power for each power class
UPS Power Controller Power
1 kVA (700 W to 800 W) P ≤ 5.5 kW
2 kVA (1400 W to 1600 W) 5.5 kW < P ≤ 11 kW
3 kVA (2100 W to 2400 W) 15 kW ≤ P ≤ 22 kW
