26.6 Cu. Ft. French Door Refrigerator
6 While turning the new filter clockwise, push it all the way into the holder until it locks into place.
7 Turn on the shutoff valve and the water supply, then run water through the dispenser until the water runs clear (about
five minutes). This cleans the water supply system and removes any trapped air.
8 Open the refrigerator door and make sure that no water leaks from the water filter.
9 After you install the new filter, press and hold both the On/Off and Super Freeze buttons for about three seconds to
turn off the icon.
Reverse osmosis system
If your cold water supply is connected to a reverse osmosis system:
• The water pressure to the reverse osmosis system needs to be between 40 psi to 60 psi (276 kps to 414 kpa).
• The water pressure at the inlet valve on your refrigerator needs to be between 30 psi to 125 psi (207 kpa to 862 kpa).
If the water pressure to the reverse osmosis system is less than 40 psi and 60 psi (276 kps and 414 kpa):
• Check the sediment filter on the system, and replace the filter if necessary.
• Allow the storage tank on the system to refill after heavy usage.
• If the water pressure is still too low, your refrigerator's water filter may be further reducing the water pressure. Remove
the water filter.
Replacing the LED light
If the LED light is damaged:
1 Unplug your refrigerator.
2 Remove the light cover by lifting it up.
3 While pressing the connector latch with one hand, pull the LED light out.
4 Replace the LED light and snap it correctly in place, then replace the light cover.
Storing your refrigerator
1 Unplug your refrigerator from the power outlet.
2 Remove all food.
3 Clean your refrigerator.
4 Take off the doors, and leave the shelves in place so that children cannot easily climb inside.
CAUTION: The LED light must be replaced by a qualified service technician.
WARNING: If a door accidentally closes while a child is inside your refrigerator, the child may suffocate.
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 30 Tuesday, June 12, 2018 9:16 AM

Insignia NS-RFD26SS9 Specifications

General

Style	French Door
Color	Stainless Steel
Number of Doors	3
Total Capacity	27.8 Cu. Ft.
Refrigerator Capacity	14.8 cu. ft.
Freezer Capacity	7 cu. ft.
Number of Refrigerator Shelves	5
Number of Refrigerator Bins	6
Humidity Controlled Crispers	2
Number of Freezer Shelves/Baskets	1 Drawer Divider
Refrigerator Temperature	-
(-14°C)	-
Refrigerator Special Features	Power Freeze and Power Cool
Freezer Special Features	DuraBase Solid Drawer Base
Defrost System	-
Noise level	-
Refrigerant	-
Energy Class	-
Annual Energy Consumption	624 kWh
Voltage	115 V
Frequency	60 Hz
Current	-

Weight and Dimensions

Depth	36 1/4 in
Height	69 5/8 in
Width	29 3/4 in
Net Weight	313 lbs
