Product Description

Table 4. HDMI Port Status Conditions

PCI Express x16 connector status HDMI port status

No add-in card installed Enabled

Non-video PCI Express x1 add-in card installed Enabled

PCI Express x4, x8, or 16 add-in card installed Disabled

ADD2 or MEC/ADD2+ card installed Disabled

1.6.1.5 Digital Visual Interface (DVI)

The DVI-I port supports both digital and analog DVI displays. The maximum

supported resolution is 2048 x 1536 at 75 Hz refresh (QXGA). The DVI port is

compliant with the DVI 1.0 specification.

Depending on the type of add-in card installed in the PCI Express x16 connector, the

DVI port will behave as described in Table 5.

Table 5. DVI Port Status Conditions

PCI Express x16 connector status DVI Digital (DIV-D)

port status

DVI Analog (DVI-A)

port status

(Note)

No add-in card installed Enabled Enabled

Non-video PCI Express x1 add-in card

installed

Enabled Enabled

PCI Express x4, x8, or 16 add-in card

installed

Disabled Disabled

ADD2 or MEC card installed Disabled Enabled

Note: DVI analog output can also be converted to VGA via a DVI-VGA converter. See note below.



NOTE

DVI analog output can also be converted to VGA via a DVI-VGA converter.
