Intel DG45ID User Manual

9
1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the Intel Desktop Board DG45ID.
Table 1. Feature Summary
Form Factor Micro-ATX (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
Processor Support for the following:
• Intel
®
Core™2 Quad processor in an LGA775 socket
• Intel
®
Core™2 Duo processor in an LGA775 socket
• Intel
®
Pentium
®
Dual-Core processor in an LGA775 socket
• Intel
®
Celeron
®
Dual-Core processor in an LGA775 socket
• Intel
®
Celeron
®
processor 400 Sequence in an LGA775 socket
Memory
• Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR2 800 MHz or DDR2 667 MHz DIMMs
• Support for up to 8 GB of system memory using DDR2 800 MHz or DDR2 667
MHz DIMMs
Chipset
Intel
®
G45 Express Chipset, consisting of:
• Intel
®
82G45 Graphics and Memory Controller Hub (GMCH)
• Intel
®
82801JR I/O Controller Hub (ICH10R)
Audio 8-channel (7.1) audio subsystem using the IDT* 92HD73E high definition audio
codec and Dolby* Home Theater certification
Video Intel
®
Graphics Media Accelerator X4500HD (Intel
®
GMA X4500HD) onboard
graphics subsystem.
Legacy I/O Control Legacy I/O controller for serial port header and Consumer Infrared (CIR)
Peripheral
Interfaces
• Twelve USB 2.0 ports: six back panel connectors and six front panel headers
• Two IEEE-1394a interfaces: one back panel connector and one front-panel
header
• Six Serial ATA (3 Gbps) interfaces, including one red-colored external Serial
ATA (eSATA) interface on the back panel
• One serial port header (may require specialized chassis or cable for use)
LAN Support Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel
®
82567LF
Gigabit Ethernet Controller
BIOS
• Intel
®
BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
continued

Intel DG45ID Specifications

General

Brand	Intel
Model	DG45ID
Category	Computer Hardware
Language	English
